Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 304

inconsistent with this entry is dialed. A call dialed as 1813410 is denied when the
digit "0" is dialed. A call dialed as 1813419+any digits, is allowed.
Digit Interval 001 is programmed as: From "0," To "#." (This allows all digits to be
dialed.)
There are one hundred (100) Interval Table entries available for programming.
System Speed can be set to Override toll restriction.
Default Settings:
Restriction – Toll Restriction – Digit Interval 001 – From = 0. (Range is any digits,
max. 10 in length.)
Restriction – Toll Restriction – Digit Interval 001 – To = #. (Range is any digits,
max. 10 in length.)
Restriction – Toll Restriction – Digit Interval 002‐100 – From/To = NULL (none).
Restriction – Toll Restriction – Digit Interval – Extension/CO Line Day/Eve COS 0 =
Y. (Range is Y/N.)
Restriction – Toll Restriction – Digit Interval 002‐100 – Extension/CO Line Day/Eve
COS 1‐7 = N.
Extension ‐ Day/Eve Class Of Service = 0. (Range is 0‐7.)
CO Line Day/Eve Class Of Service = 0. (Range is 0‐7.)
Deluxe Telephone Programming
1. Access the Database Item Selection Screen using the procedures in Section
3.2.
Program Digit Interval(s) and assign Extension/CO Line COS to Digit Intervals:
2. Enter 05-01- Tenant Group -001-100 and then press the softkey
beneath save . This advances to the FROM column of the tenant group and
interval selected.
3. Press the softkey beneath chg to change the start of this interval range
(beginning FROM...).
4. Enter the new starting digit sequence, then press the softkey beneath
save .
5. Press the softkey beneath next to advance to the TO column of the tenant
group and interval selected.
6. Press the softkey beneath chg] to change the end of this interval range
(up ...TO).
Emerald ICE Installation, Programming & Maintenance Manual
9-5
