RMP Layout
To make the RMP clear and easy to operate, the RMP provides a Windows‐based,
Graphic User Interface (GUI) which can be run using Microsoft
RMP's Main Window contains five areas:
• Title bar
• Menu bar
• Client Window
• Status Bars
A brief description of the functionality of each component is provided below,
whereas the detailed specification of the functions of the RMP will be described in
the chapters herein.
Title Bar
The Main Window's Title Bar displays "Remote Maintenance & Programming ‐
Untitled" if the RMP is invoked without a file name. The active file name will
replace "Untitled" once it has been saved and given a new name. When the
application is run, it opens a new document, therefore "Untitled" is displayed. If
the user opens an existing database, the database name will replace "Untitled" in
the title bar.
Menu Bar
This is where users perform most of the functions provided by the RMP. Clicking
on a menu item will pull down a menu list. In several cases the menu selection
could have sub‐menus.
Client Window
The only purpose of the Client Window is to display the logo and the version
information.
Status Bars
Two Status Bars are provided to present the real‐time status of RMP. The upper
part is Communication Port Status Bar, and the other is Message Status Bar.
