Attendant / Extension DSS Console

Description
The Attendant/Extension DSS Console is a self contained digital terminal that
interacts with a predetermined Deluxe Telephone. The console has 60
programmable buttons that can be used for easy access to the Emerald ICE systems
many CO lines, extensions and features. The first forty‐eight buttons have dual
colored LED's that allow status monitoring of system resources such as CO Lines
and Extensions. The remaining twelve buttons on the Attendant/Extension
Console may be used for any system feature or resource but are not equipped
with LED's.
Although usually considered to be an attendant feature benefit, the DSS Console
can be assigned to any Emerald ICE Deluxe Telephone. A maximum of twelve (12)
sixty‐button Attendant/Extension Consoles may be added to the system. Each
requires its own dedicated digital port and therefore reduces the number of
Deluxe Telephones that can be connected to the system on a one‐to‐one basis. Any
digital extension may be assigned four Attendant/Extension DSS Consoles
maximum.
Each DSS Console has 40 dual‐color LED buttons and 12 buttons without LEDs.
Each DSS Console required its own dedicated cable pair from the KSU.
12 maximum DSS Consoles can be assigned in the Emerald ICE system.
4 maximum DSS Consoles can be assigned to any one Deluxe Telephone
(extension/attendant).
Default Setting:
No Attendant/Extension Consoles are assigned in default.
Deluxe Telephone Programming
1. Access the Database Item Selection Screen using the procedures in Section
3.2.
2. Enter 04-14-01-01 and press the softkey beneath save . This advances
to the DSS OWNER programming of DSS Console #1.
3. To change the designated DSS Console Owner press the softkey beneath
chg and enter the extension number to be assigned as the DSS Console
Owner.
