Configuration Flexibility

2.19
The Emerald ICE can be configured with single or dual cabinets.
• Minimum (610+2): 6 CO lines + 10 digital +2 analog stations (single cabinet)
• Maximum (1232): 12 CO lines + 22 stations + 10 SLT (single cabinet)
...or (1628): 12 CO lines + 4VoIP channels + 22 stations + 6 SLT (single
cabinet)
• Growth with second cabinet: can be expanded to (1840), including 18 CO
lines + 22 stations + 18SLT...
...or (2464), including 24 CO lines + 46 stations + 18SLT
...or (2852), including 24 CO lines + 4 VoIP channels + 46 stations + 6
SLT
...or (4052), including 12 CO lines + 24 T1/PRI channels + 4 VoIP
channels + 46 stations + 6 SLT Only one VoIP gateway is allowed in
cabinet 1.
• Only one 6CO board installation is allowed when T1/PRI is equipped in 2nd
Cabinet.
The following combinations with different configurations can be generated:
1. First cabinet ‐ Maximum: equipped with 7 boards (including VAA/IVM on
CCB) CCB + (610+2)(6CO+10EKT+2SLT) + 6CO + 12EKT + 4SLT + 4SLT +
VoIP gateway .
