Modem Module - Tadiran Telecom Emerald ICE Installation Manual

2.10
Figure 2-10 Modem
Module
2-12
Emerald ICE Installation & Hardware Reference Manual

Modem Module

The Modem Module is a self‐contained integrated modem unit that is installed at
J5 and J6 in the lower left corner of the CCB. The integrated Modem Module
allows the servicing Telephone Company to access the telephone system
programming and remote maintenance utilities from an off‐site location (password
verification required).
When installed, the servicing technician uses the RMP and a modem (in the PC) to
place a call to the site where the Emerald ICE is installed. If one of the voice
processing systems are installed, routing to the modem extension is automated.
Otherwise the person who answered this data call must transfer the call to
Extension 400 (Default). Once the modems have established the data connection,
RMP may be used to perform all servicing operations.
The only configurable parameter in the Modem Module is the Baud Rate. Baud
rate can be configured to 1200 or 2400 by using the RMP or the Deluxe Telephone
set.
