Tadiran Telecom Emerald ICE Installation & Maintenance Manual page 331

11-2
Emerald ICE Installation, Programming & Maintenance Manual
Deluxe Telephone Programming
1. Access the Database Item Selection Screen using the procedures in Section
3.2.
Program CO Line Groups for Alternate CO Line Groups:
2. Enter 07-01 ‐CO Line Group -03 and pess the softkey beneath save .
This advances to the ALTER. ROUTE programming screen.
3. Press the softkey beneath show . The display shows ALTER. CO GP
:_.
4. Enter the Alternate Route to program (1 for first alternate, or 2 for second
alternate) for this CO Line Group.
5. Press the softkey beneath show . The display shows CO GP NUMBER :
X. (Where x is the current programming, 0 means no alternate route. To
change this Alternate Route selection, press the softkey beneath chg .
6. Enter the CO Line Group that is to be used as the (1st or 2nd) Alternate
Route for this CO Line Group and press the softkey beneath save .
7. Press the softkey beneath next to advance to the DELETE DIGITS
screen for this Alternate Route selection. If it is necessary to delete digits
from the dialed digits when calls are routed to this alternate, put in the
number of digits to delete here.
8. Press the softkey beneath chg and enter the quantity of digits to delete
from the beginning of the number dialed. (0‐9)
9. Press the softkey beneath save .
10. Press the softkey beneath next to advance to the INSERTED DIGITS
screen for this Alternate Route selection. If it is necessary to insert digits
before sending the dialed digits when calls are routed to this alternate,
enter the actual digits required here.
11. Press the softkey beneath chg and enter the required digits. (Up to 16
digits may be inserted.)
12. Press the softkey beneath save .
13. Press the softkey beneath next . The display shows ALTER. CO GP
:_. The next Alternate Route may now be programmed for this CO Line
Group (if required).
14. Enter the Alternate Route to program (1 for first alternate, or 2 for second
alternate) for this CO Line Group, press the softkey beneath show and
continue programming as per the first alternate programming.
15. Press the Volume button (
v
) to return to the DB Item Select Screen.
