NetSure™
LMS Data Processing Unit
User Manual (Section 5847), Revision ZA
Specification Number: 586505000 and 586505500
Model Number: LMS1000
Firmware Version 12.3
Also for the LMS Monitoring System factory integrated into Spec. Nos.
582140000, 582140001, and 582126100 NetSure™ Power Systems (NPS)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetSure LMS1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Vertiv NetSure LMS1000

Summary of Contents for Vertiv NetSure LMS1000

  • Page 1 NetSure™ LMS Data Processing Unit User Manual (Section 5847), Revision ZA Specification Number: 586505000 and 586505500 Model Number: LMS1000 Firmware Version 12.3 Also for the LMS Monitoring System factory integrated into Spec. Nos. 582140000, 582140001, and 582126100 NetSure™ Power Systems (NPS)
  • Page 2 The information contained in this document is subject to change without notice and may not be suitable for all applications. While every precaution has been taken to ensure the accuracy and completeness of this document, Vertiv assumes no responsibility and disclaims all liability for damages resulting from use of this information or for any errors or omissions.

  • Page 3: Table Of Contents

    General ..................................33 Screen Updates ..............................33 File Transfers ................................ 33 Vortex Plants ............................... 34 Setting Up the Web Interface ........................34 IP Address ................................34 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 4 Operation – Manual Connection With No Profile: ..............58 Operation – Manual Connection with a Profile: ................59 Operation – Global Command Connection: ..................59 Operation – Gateway Session Termination Message: ............60 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 5 System PCU Minor Alarm and PCU Major Alarm ............. 98 VPS Fuse Alarm and VPS All AC Off Alarm ................98 Other VPS Status ............................. 99 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 6 ACO ..................................... 124 AID ....................................125 ALARMS ................................. 125 ALARMS NETSURE ............................ 128 ANSWER ................................133 BATTERY ................................134 BATTERY THERMAL ..........................135 BATTERY TIMER ............................136 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 7 DOWNLOAD TFTP NETSURE ......................183 DOWNLOAD NPS............................184 DOWNLOAD NETSURE .......................... 185 EFF ....................................186 EVENTS .................................. 187 HELP ..................................190 HELP NETSURE ............................. 198 INFO .................................... 201 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 8 SET DEFAULTS ............................. 274 SET EFF ................................. 276 SET EMAIL ................................277 SET GATEWAY ...............................278 SET INFO ................................279 SET LED ................................280 SET LIMITS ................................. 281 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 9 SET NPS SYSTEM UPDATEINV ..................... 327 SET NPS SYSTEM USECELSIUS ....................328 SET NPS SYSTEM USEFAHRENHEIT ..................329 SET NPS SYSTEM VERYLOWVOLT ..................330 SET PERIODS ..............................331 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 10 SET NETSURE SYSTEM CALVOLT ................... 381 SET NETSURE SYSTEM COMPMAX ..................382 SET NETSURE SYSTEM COMPMIN ..................383 SET NETSURE SYSTEM COMPSLOPE .................. 384 SET NETSURE SYSTEM COMPSOURCE ................385 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 11 Command Options ............................425 Commands ................................... 426 IP ....................................426 IP ADDRESS ..............................427 IP DELETE ................................428 IP GATEWAY ..............................429 IP HOST ................................. 430 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 12 INITIALIZE SYSTEM (INIT-SYS) ....................469 OPERATE-ALARM CUTOFF (OPR-ACO-{EQPT|ALL}) .......... 471 OPERATE-EXTERNAL-CONTROL (OPR-EXT-CONT) .......... 472 RELEASE-EXTERNAL-CONTROL (RLS-EXT-CONT) ..........473 RETRIEVE-ALARM (RTRV-ALM-{EQPT|ALL}) ............. 474 RETRIEVE-ALARM-ENVIRONMENT (RTRV-ALM-ENV) ........477 RETRIEVE-ATTRIBUTE (RTRV-ATTR-{EQPT|ALL}) ..........479 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 13 Circuit Cards ................................525 Replacement Circuit Card Part Numbers ..................525 Replacement Procedures ........................525 Replacing a 586505000/586505500 Main Cabinet or 582140000/582140001/582126100 Primary Bay CPU Circuit Card ..... 525 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 14 Replacing an Expansion Cabinet CPU Circuit Card ............. 528 Replacing a 586505000/586505500 Expansion Assembly ........532 Modem Circuit Card Replacement ......................532 I/O Circuit Card Replacement........................532 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 15: Admonishments Used In This Document

    SAFETY! Informs the reader of general safety information, reminders, precautions, or policies not related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 16: Static Warning

    If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist strap, work on a conductive surface, use a grounded soldering iron, and use grounded test equipment. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 17: Fcc Information

    The following information is provided here and on a label attached to the outside of the MCA Interface Modem Option (if installed). JACK RINGER EQUIVALENCE FCC REGISTRATION NUMBER RJ-11 0.2A B46USA-22429-MM-E Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 18 This Page Intentionally Blank. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 19: Introduction

    Analog, binary, relay, and temperature circuit cards (I/O cards) can be provided to monitor equipment external to the Power Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 20: Lms1000 Consists Of

    TL1 port, and Ethernet Port (for Telnet access, Web access, SNMP access, optional TL1 access, and Email alarm reporting). Additional OEM ports are provided. The functions of the OEM ports are Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 21: Lms1000 Provides

    • Automatically detected (identified) I/O circuit cards. Circuit cards are automatically identified by system firmware on power-up. • CPU Firmware can easily be upgraded by a Vertiv Co. service facility via a local or remote terminal interface. • System configuration can easily be downloaded from LMS1000 to a PC (locally or remotely), and uploaded from a PC to LMS1000 (locally or remotely).
  • Page 22 Sequential Start (relays are not required for a Vortex Power System) * Software Dependent: See Lists 60, 61, 79, 84, 85, 86, and 88 descriptions in SAG586505000/SAG586505500. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 23: Operating Lms1000

    Secondary Bays. Both the Primary and Secondary Bays provide mounting slots for the optional LMS1000 I/O circuit cards. The LMS1000 easily interfaces with the MCA (Meter-Control-Alarm) Assembly of a Vertiv Co. VPS and NPS Power System. There is no need for separate LMS1000 I/O circuit cards for this interface. All LMS1000 monitoring and controlling capabilities for the MCA Interface are built into the LMS1000 primary CPU circuit card.

  • Page 24: Nodes

    • The LMS1000 also provides self-diagnostic alarms on binary channels B0081 through B0096. Example: A0001, A represents an analog input/channel 00 represents the 586505000/586505500 Main Cabinet Node or 582140000/582140001/582126100 Primary Bay LMS1000 I/O Grouping Node (cannot Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 25: Local Controls And Indicators

    586505000/586505500 System, these indicators are visible through the front panel of the Main and Expansion Cabinets. In the 582140000/582140001/582126100 Power System, open the bay's front door to view the indicators on the LMS1000 CPU circuit card. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 26 S2 (Programmable Switch) (Main CPU Circuit Card Only): Can be used in program lines. Refer to "Program Lines" in "Configuring LMS1000" in the separate Installation Instructions (Section 5879). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 27 Located on Front of Main LMS CPU Circuit Card MAIN CABINET 586505000 Shown 586505500 Similar FRONT OF SHELF Located on Front of Expansion LMS CPU Circuit Card EXPANSION CABINETS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 28: Accessing The System Through A Local Or Remote Terminal

    1 stop bit and half-duplex. This capability may also be achieved using a personal computer running a special "terminal emulator" program such as the Lorain® SMART Partner. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 29: Local Terminal Access

    Command Prompt: The command prompt indicates that the system is waiting for user input, and is shown below. In this prompt, n denotes the level of access. Command <n>: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 30 It is NOT active during the processing of a command. NOTE! Commands such as SCAN Annnn n will run indefinitely until the user aborts the command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 31: Logging On To The System

    "Command <n>:". In this prompt, n denotes the command access level of the current user. Commands (that the user has access to) may now be entered. The command BYE should be entered to terminate the communication link when finished. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 32: Callback Feature

    • Displays LMS status, history, and inventory in Web pages. • User configurable status pages and channel groups can also be displayed in the status Web pages. • Provides three (3) editable pages for notes. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 33: Requirements

    To update a screen before its regular interval, click on another screen and then return to the desired screen. File Transfers Recall the LMS is capable of downloading two configuration files: one for the LMS, the other for NPS settings. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 34: Vortex Plants

    • Load Current Channel - F0063 Custom Pages You can configure your own personal LMS1000 Web pages for the following. • Status Pages • Channel Group Pages Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 35: Access Levels

    Login Lockout Feature: You have three (3) attempts to enter a valid User Name and password. After three (3) unsuccessful attempts to login, the LMS locks you out for two (2) minutes. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 36: Homepage

    When clicking on a different Menu Group, the current one collapses. When you return to a Menu Group, the group expands and the last view page is displayed. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 37: Main View Area

    Displays active LMS alarms. Click the tabs to view alarms on specific channel types. Note that the alarms are displayed in red text. This view is equivalent to the LMS ALARMS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 38: Channels" Status View

    Lists the present value and alarm status of each channel. Click the tabs to view the different channel types. This view is equivalent to the LMS SCAN command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 39 Navigate to the channel to be added as a User Channel. Select the “User #x” check box. Click the “Submit” button. Repeat for additional channels to be added. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 40: Power" Status View

    The Aux view is a listing of all auxiliary distribution load currents. The Settings view is a list of all power system settings and is equivalent to the commands PR NPS SETTING and PR NPS MCA. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 41: Status Pages" View

    “Status Pages” View Displays the LMS status page. See next section for programming instructions. This view is equivalent to the LMS STATUS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 42 Change the name as desired. Enter channel numbers as desired. Hint: Click on the Active Channels arrow to display a list of channels to choose from. Click the “Submit” button. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 43: Group Pages" View

    Displays the basic statistics for analog and function channels set in groups. See next section for programming instructions. This view is equivalent to the LMS SCAN Gn command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 44: Configuring Group Pages

    Navigate to the channel to be added to a Group. Select the “Group #” check box. Click the “Submit” button. Repeat for additional channels to be added to a Group. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 45: History" Menu Group

    Displays the LMS alarms log. NOTE! The “Recent” tab displays the thirty (30) most recent alarm log entries. This view is equivalent to the LMS LOG command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 46: Event Log" View

    “Event Log” View Displays the LMS events log. This view is equivalent to the LMS EVENTS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 47: Min/Max/Avg" View

    “Min/Max/Avg” View Displays the basic statistics for analog and function channels. This view is equivalent to the LMS STATS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 48: Distr. Capacity" View

    For a channel to appear in the report, one of its alarm limit names must contain the text SIZ or CAP. This view is equivalent to the LMS RATE command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 49: Daily/Weekly" View

    This view is equivalent to the STATS DAILY command. Weekly Tab Displays the Weekly Advanced Statistics for analog and function channels set for Advanced Statistics. This view is equivalent to the STATS WEEKLY command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 50: Inventory" Menu

    “Inventory” Menu Displays the LMS inventory. This view is equivalent to the LMS BOARDS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 51: Notes" Menu

    Three (3) editable pages for notes are available. Select the tab to edit or enter notes in. Click the “Edit” button to add notes. Click the “Submit” button to save the notes. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 52: Configuration" Menu Group

    This view is equivalent to the SET CLASS, SET PERIODS, SET PROGRAM commands. NOTE! Press the Help button for a listing of the valid terms and operators, plus example control programs. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 53: Channels" View

    Allows configuration of analog and binary inputs, LED indicators, control relays, function channels, and energy management channels. Also allows assigning channels to channel groups and User channels. This view is equivalent to the CONFIG command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 54: Power" View

    Also allows you to upload and download MCA configuration files. Allows you to update inventory. This view is equivalent to the SET NPS, DOWNLOAD NPS, and UPLOAD NPS commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 55: Settings" View

    TRAPS ADD, TRAPS COMMUNITY, TRAPS DELETE, TRAPS OCCURRED, TRAPS OFF, TRAPS ON, TRAPS PERSISTENT, TRAPS RETIRED, TRAPS VERSION, SET EMAIL, NODE ADD, NODE CONFIG, NODE DELETE, NODE INITIO, NODE REPLACE, SET COM, UPLOAD, DOWNLOAD, and SET DEFAULTS commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 56: Users" View

    “Users” View Allows you to configure Users. This view is equivalent to the SET USERS command. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 57: Accessing Lms1000 Via Telnet And Tftp

    Messages which are pending at the time or after the handshake input becomes inactive will be sent when the handshake input is returned to the active state. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 58: Using The Tl1 Port

    In this mode the LMS1000 connects the user’s terminal device to the Gateway Port device without any processing. The user must then make entries on their terminal interface to initiate whatever action is required of the Gateway device. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 59: Operation - Manual Connection With A Profile

    LMS1000. NOTE! This requires that the DGU connected to the Gateway Port have the same passwords as the users on the LMS1000. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 60: Operation - Gateway Session Termination Message

    • Loss of Carrier: The LMS1000 will automatically terminate a Gateway Port session established via modem dial up or TELNET in the event of a loss of carrier or network connection. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 61: List Of Lms Commands Accepted As Gateway Port Global Commands

    This command is available to users programmed for access to level 6 commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 62: Using The Alarm Cutoff Feature

    Manual: The command CLR ACO releases, or "uncancels", the alarm cut-off feature thereby enabling analog, function, and binary channel alarm conditions to again affect the relay channels' control Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 63: Forcing On Relays Or Led's

    An or Fn (n=channel number) with the CLR STATS command (ex. CLR STAT A0001 or CLR STAT F0001). Refer also to the descriptions of these commands in the COMMANDS section. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 64: Advanced Statistics

    These percentages inform the customer how close a channel's peak and high hourly average values are in relation to its alarm limit(s). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 65: Viewing And Clearing The Alarm Log

    NPS MCA alarms, refer to Table 2 and ensure that the desired channels automatically mapped to predetermined NPS MCA alarms are programmed for system alarm reporting and/or added to the appropriate user configuration. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 66 Occurred date and time. If the alarm has been acknowledged by a user, the user number appears after the occurred time. Cleared date and time. A lowercase character r if the alarm is to be reported as a system alarm. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 67: Viewing And Clearing The Event Log

    TL1 Report Messages enabled or disabled. "4 chan Relay bd <#n> fail". "Com link to MCA broken". "Chn <type, node#, channel#> statistics cleared". "Function channel stats cleared". Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 68 HTML checksum failure. VI parameters set. Battery Discharge Timer set. Key code nn validated. Invalid Key Code entered. System Alarm Report parameters set. Daily/weekly statistics cleared. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 69 Temperature probe high alarm set Temperature probe low alarm set Digital temperature compensation source set Relay test time set Test/Equalize time set VPS/NPS interface enabled VPS/NPS interface disabled Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 70 Battery current limit set Temperature probe high alarm set Temperature probe low alarm set Digital temperature compensation source set Relay test time set Test/Equalize time set Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 71 NPS MCA load A/B activated NPS MCA load A/B deactivated NPS dist. bb-cc LD B enabled NPS dist. bb-cc LD A enabled System float voltage set System equalize/test voltage set Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 72 I/O Bd bb-ss output scale set I/O Bd bb-ss load type set I/O Bd bb-ss binary input dd alarm orientation changed NPS MCA auxiliary load deactivated Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 73: Using Status Pages

    Lines 2 - 18: Type one of the following characters per line to display Header or SCAN Information when the command STATUS is executed. A=Analog Channel Header B=Binary Channel Header E=Energy Management Channel Header F=Function Channel Header Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 74: Using Information Pages

    Since each user may not necessarily be concerned about the same information, several methods exist whereby a user can limit the information displayed when using a local or remote terminal. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 75: Downloading And Uploading The Configuration

    The communications parameters of the remote terminal must match the system's default parameters. The default parameters are 8 data bits, 1 stop bit, and no parity. These defaults cannot be changed. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 76 The CLR PROG command may be used instead of re-editing the upload file. Refer to the CLR PROG command in the COMMANDS section. 202 blocks received OK. R01=h1 Program error -- Bad Character Upload Complete. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 77: Downloading And Uploading Using Tftp

    LMS1000. NOTE! Only one LMS1000 user is allowed to change VPS/NPS settings at a time. LMS1000 locks out any other user attempting to change VPS/NPS settings. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 78 VPS/NPS Temperature Probe #1 through VPS/NPS Temperature Probe #8 B9001 VPS/NPS System High Voltage 1 B9002 VPS/NPS System High Voltage 2 B9003 VPS/NPS System Battery On Discharge Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 79 NETSURE. This command is available to a user with access to level 1 commands. Viewing VPS/NPS Settings and Equipment Inventory: Use the command PRCONFIG NETSURE. This command is available to a user with access to level 2 commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 80 This command is available to a user with access to level 6 commands. Setting VPS/NPS High Voltage Shutdown: Use the command SET NETSURE SYSTEM HVS. This command is available to a user with access to level 6 commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 81: Accessing An Nps Power System

    ‘NETSURE’). Reference to an LMS in a Spec. No. 582140000, 582140001, and 582126100 NPS Power System will be NPS (LMS commands and responses specific to this interface use ‘NPS’). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 82 NPS Plant Voltage A9902 Total Charger Output A9903 Total Load Current A9904 Group A Load Current A9905 Group B Load Current A9906 reserved A9907 Temperature Sensor Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 83 B9929.09 Display Fail B9929 B9929.10 Temperature Sensor No Reply B9929.11 Any NPS Router Fail Alarm Exists B9929.12 Any NPS Relay Board Fail Alarm Exists B9929.13 MCA Memory Failure Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 84 MCA Relay Fcn Rectifier Minor B9960 MCA Relay Fcn Over Current B9961 MCA Relay Fcn AC Major B9962 MCA Relay Fcn AC Minor B9963 MCA Relay Fcn MCA Fail Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 85 Ann49 reserved Ann50 reserved 582140000 Only PCU nn-01 Load through Ann51 PCU nn-10 Load through Ann60 nn = Bay Number 582140000 Only Ann61 reserved through Ann90 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 86 27-30, channels are A0127 and B0127. For a triple pole element in positions 31-36, channels are A0131 and B0131. For a quad pole element in positions 37-44, channels are A0137 and B0137. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 87 Alarm Log Sub-ID Entries (nn is a Bnnnn.09 Fuse / Circuit Breaker Alarm Distribution Only Bay) Bnnnn.10 Shunt Overcurrent Alarm Bnnnn.11 Shunt was Removed Bnnnn.12 Unknown Element Alarm Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 88 Bnn50.09 CAN I/O Processor Fail Bnn50 Bnn50.10 CAN I/O Communications Fail Bnn50.11 CAN I/O Duplicate Node Bnn50.12 Shunt Output Overcurrent Alarm Bnn50.13 Shunt Input Overcurrent Alarm Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 89 Bnnnn.27 Thermal Shutdown (MJ) Bnnnn.28 Thermal Current Limit (MJ) Bnnnn.29 PF HV Shutdown (MJ) Bnnnn.30 Converter Unbalanced (MJ) nn = Bay Number 582140000 Only Bnn61 reserved through Bnn90 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 90 5 commands. Setting NPS Relay Test On: Use the command SET NPS SYSTEM RLYONTEST. This command is available to a user with access to level 6 commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 91 SYSTEM HI1TEMPALM, SET NPS SYSTEM HI2TEMPALM, SET NPS SYSTEM LOW1TEMPALM, and SET NPS SYSTEM LOW2TEMPALM. These commands are available to a user with access to level 5 commands. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 92: Viewing Software Options Installed

    F0001=A0001*(A0002+A0003)*0.001 This example also describes a program line for a single load with multiple shunts or fuses monitored by A0002 and A0003. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 93: Using Power Metering

    03/14/99 THROUGH 03/31/99: 1868.0 KWH 04/01/99 THROUGH 04/29/99: 3098.0 KWH F0003 POWER STATS: CUST BOB LOADA AND LOADB POWER Daily 04/28/99: 147.40 KWH 04/29/99: 79.85 KWH Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 94: Clr Power Command

    “Option Name”. Look for “installed, enabled” under the “Status” column heading. If the Power Metering option’s status is listed as “not installed”, contact Vertiv Co. and tell them you would like the Power Metering option installed on your LMS1000.

  • Page 95: What Do I Need, How Do I Order

    Foremost you’ll need to specify the Power Metering option. Specify 586505000/586505500 List 87. Note that this option must be factory installed, or field installed by Vertiv Co. only. Note this option can be field installed remotely via dial-up phone lines if your LMS1000 is equipped with a modem or via Ethernet if connected to a TCP/IP network.

  • Page 96: Setting Up The Lms Dual Mca Interface Feature

    SET NPS SYSTEM TSTEQVOLT System Test/Equalize Timeout SET NPS SYSTEM TSTEQTIME SET NPS SYSTEM System Auto Equalize Multiplier EQMULTIPLIER System ACO Timeout SET NPS SYSTEM NAGTIMER Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 97: Changing Vps Specific Settings

    SET VORTEX INTERFACE Interface SET VORTEX LVD<n<t>> Manually Reconnect LVD(s) FORCECON PCU Fan Speed SET VORTEX PCU FANSPEED Subsystem Calibration Voltage SET VORTEX SUBSYSTEM to Factory Default FACTORYCAL Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 98: Vps System Current

    AC Fail alarm inputs can be included by adding them to the program line of LMS LED channel L8. Refer to Program Lines in the ‘Configuring LMS1000’ section of the Installation Instructions (Section 5879). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 99: Other Vps Status

    The information displayed includes the duration of the battery discharge, the time and date at which the discharge began, the lowest recorded plant voltage during the discharge, and the average plant load. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 100: Setting Up The Battery Discharge Timer Feature

    Refer to the documentation furnished with the AC Analyzer. LMS1000 AC Analyzer Interface is 9600, n, 8, 1. Set the AC Analyzer to 9600, n, 8, 1 as node #1. The following LMS1000 analog and binary channels are added. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 101: Lms1000 Input Signal And Alarm Limit Processing

    ‘Polarity’ and ‘Alarm Limit Mode’, which govern how high and low alarm thresholds operate. The standard method used for alarm processing generates a high alarm when the reading is greater Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 102 To process an analog channel’s alarms using this method the channel’s polarity parameter is set to ‘+’ and its alarm limit mode parameter is set to ‘B’ (for Bipolar). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 103: Discharge

    • F61: Function Channel F61 provides a plant's "Battery Reserve (Charge) Time” in minutes. See the next section. • F62: Function Channel F61 provides a plant's "Plant Voltage (for Fuel Gage)” in minutes. See the next section. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 104: Lms Battery Fuel Gage And End-Of-Life Warning

    • The initial value is estimated and is the Rated Capacity (limit F61.1) minus the elapsed time on discharge. • A valid prediction by the algorithm takes 40-60 minutes depending on the discharge rate; updates every Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 105 IEEE-1188 Recommended Practice for Maintenance, Testing, and Replacement of VRLA Batteries for Stationary Applications F59 limits default to zero and update during the highest prediction occurring within the first 6 months (of initial clock setup) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 106: Commands

    Advanced Statistics list programmable commands list local comm port settings CONFIG <tn> configure specified channel CONNECT initiate a communications session with device connected to GATEWAY port Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 107 SCAN list active channel status SEQUENCE show AC & standby sequencer status list SET type commands SET ACO cutoff present alarms from affecting relays Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 108 TIME show date and time TIMEOUT show user timeout UNIT show unit name and number UPLOAD configure the system by uploading a file using XMODEM protocol Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 109: Vps/Nps Power System Interface Commands

    VPS/NPS Power System configuration using XMODEM protocol HELP NETSURE list of VPS/NPS Interface commands with a description of each PRCONFIG NETSURE list VPS/NPS Power System settings and equipment inventory Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 110 FACTORYCAL SET NETSURE set subsystem High Voltage alarm SUBSYSTEM HIVALM SET NETSURE set subsystem Low Voltage alarm SUBSYSTEM LVALM Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 111 SET NETSURE SYSTEM set system High Voltage 2 Alarm HIVLTALM2 SET NETSURE SYSTEM set system High Voltage Shutdown SET NETSURE SYSTEM reset the system equipment inventory INVENTORY Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 112: Nps Power System Interface Commands

    This section provides an alphabetical list of all NPS Power System Interface commands, with a short description of each command. NPS Power System Description Interface Commands Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 113 High Voltage 1 alarm HIVLTALM1 SET NPS SYSTEM set system High Voltage 2 alarm HIVLTALM2 SET NPS SYSTEM HVS set system High Voltage Shutdown Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 114 NPS Power System by uploading file using XMODEM protocol where: < > anything enclosed in brackets is optional # is a valid number N is a valid number Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 115: Ip Networking Commands

    Persistent Alarms reporting interval TRAPS RETIRED disable/enable the system’s ability to send SNMP Retired Alarm TRAPS TRAPS VERSION <V1/V2> change the version of SNMP TRAPs sent by the system Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 116: Tl1 Commands Supported

    Instructs the system to activate a specified relay channel to operate an OPR-EXT-CONT external control. RELEASE-EXTERNAL-CONTROL Instructs the system to de-activate a specified relay channel to release an RLS-EXT-CONT external control. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 117 SET-SID given value. SET-THRESHOLD Instructs the system to set threshold levels (alarm limits) for a monitored SET-TH-{EQPT} parameter that, when exceeded, will trigger an automatic message. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 118 LMS1000 COMMANDS, VPS/NPS POWER SYSTEM INTERFACE COMMANDS, NPS POWER SYSTEM INTERFACE COMMANDS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 119: Lms1000 Commands, Vps/Nps Power System Interface

    Vortex/NetSure Power System using the LMS Dual MCA feature, the LMS commands and responses specific to the Vortex/NetSure Power System are changed from ‘NETSURE’ to ‘VORTEX’. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 120: Sample Command

    Notes: This section discusses important points related to the use of the command, such as limitations or warnings. Related Commands: Lists related commands. Example: Shows one or more examples that illustrate how to use the command plus a typical screen display. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 121: Command Conventions And Options

    [node_number] channel_number – [node number] channel number, example A1-201. node_designator Nnode_number, example N12. node_range Nnode_number – node_number, example N1-3. group_number Any number 1 through 8. group_designator Ggroup_number. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 122 Designates the power system's Low Voltage Disconnect circuit. Valid numbers are 1 to LVD_side Designates the side of the power system's Low Voltage Disconnect circuit. Valid letters are A and B. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 123: Commands

    Analog Channel 1 MAJOR 01/01 11:22:54 01/01 11:22:59 B0001 Binary Channel 1 MINOR 01/01 11:22:46 01/01 00:00:00 A0001.2H Analog Channel 1 MAJOR 01/01 11:22:43 01/01 11:22:52 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 124: Aco

    A0001 Analog Channel 1 +20.4 Amps 20.0 H - Hi Limit 2 MAJOR Chan Description Status Alarm Status / Class B0001 Binary Channel 1 active MINOR Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 125: Aid

    ACCESS IDENTIFIER 2 CONFIGURATION: Name: EMLIGHT Type: CHANNELS: None ALARMS Description: Lists active analog, binary, function, relay, and LED alarms and their channel number. Also lists self diagnostic alarms. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 126 RELAY CHANNEL ACTIVE ALARMS AS OF 11:24:20 ON 01/01/01. Chan Description Status Alarm Status / Class R0001 Relay Channel 1 On ,Pg active MINOR BINARY CHANNEL ACTIVE ALARMS AS OF 13:45:44 ON 05/13/96. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 127 Chan Description Status Alarm Status / Class B0083 Node Communication Error active B0089 Node I/O H/W Failure active B0090 Analog H/W Configuration Err active Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 128: Alarms Netsure

    The following is displayed if the selected PCU is not installed in the system. Command<2>: ALARMS N PCU[n] Which PCU (1-56)? PCU ## not installed in system Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 129 The following is displayed when a subsystem is not installed: NETSURE SUBSYSTEM ACTIVE ALARMS AS OF xx:xx:xx ON xx/xx/xx. Chan Description Alarm Status / Class No Subsystem Installed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 130 B9012 NETSURE MCA Fail active B9013 NETSURE LVD Active active B9014 NETSURE LVDs Inhibited active B9015 NETSURE System Major active B9016 NETSURE System Minor active Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 131 The following is displayed only for active potentiometer controlled LVDs: [LVD 3A] [active] [LVD 3B] [active] [LVD 4A] [active] [LVD 4B] [active] ___________________________________________________________________________________ Command<1>: ALARMS N PCU[n] Which PCU (1-56)? Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 132 Input Switch OFF active Emergency Stop active Thermal Current Limit active Conversion Element Fail active Circuit Breaker is Open active A/D Failed active Fan slowed or stopped active Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 133: Answer

    Description: Displays the number of rings that will occur before the system’s modem answers a phone call. Command Level: 5 Syntax: ANSWER Comments: The default setting is 1. Notes: none Related Commands: SET ANSWER Example: Command<5>: ANSWER Rings before answer: 1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 134: Battery

    Notes: Only the commands that the user has access to are listed. Related Commands: BATTERY TIMER, BATTERY THERMAL Example: Command<6>: BATTERY Which BATTERY command? TIMER THERMAL Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 135: Battery Thermal

    Related Commands: none Example: Command<6>: BATTERY THERMAL Battery Thermal Alarm Channel: Battery Thermal Alarm Channel: B0001 Battery Thermal Runaway Voltage: Battery Thermal Runaway Voltage: 48.60 VDC Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 136: Battery Timer

    Notes: Only the commands that the user has access to are listed. Related Commands: BATTERY TIMER CLR, BATTERY TIMER CSV, BATTERY TIMER SET, BATTERY TIMER STATUS Example: Command<6>: BATTERY TIMER Which action? STATUS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 137: Battery Timer

    Command<6>: BATTERY TIMER STATUS ? BATTERY TIMER STATUS Shows Battery Discharge History and current status ___________________________________________________________________________________ Command<6>: BATTERY TIMER SET ? BATTERY TIMER SET Sets Battery Discharge Timer Configuration Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 138: Battery Timer Clr

    Example: Command<6>: BATTERY TIMER CLR WARNING!!! This command will delete all battery discharge history. Do you wish to continue (YES or NO):YES Battery discharge history cleared Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 139: Battery Timer Csv

    Command<6>: BATTERY TIMER CSV Discharge #,Duration, AC Fail Time, AC Fail Date, Lowest Voltage, Avg. Current D01,00:00,09:20,02/26/03, 27.00, 88.00, D02,00:07,09:12,02/26/03, 27.00, 88.00, … D50,00:07,15:12,02/14/03, 27.00, 88.00, Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 140: Battery Timer Set

    WARNING!!! The Plant Voltage and Load channels are used by both the BATTERY TIMER and VI features Plant Voltage: F0001 Plant Voltage: Plant Load: F0002 Plant Load: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 141: Battery Timer Status

    88.00 D26 00:07 09:12 02/24/03 27.00 88.00 D02 00:07 09:12 02/26/03 27.00 88.00 … D25 00:07 09:12 02/25/03 27.00 88.00 The system is NOT on battery Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 142: Boards

    Dist. Panel 01 0050462976 I/O board 02-03 0085394178 Node #21 Name: Expansion Assembly Card Description Version Status 8 Binary/24 Shunt 2.1.0 Node #22 Name: Expansion Chassis Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 143 Command<2>: boards 22 Node #22 Name: Expansion Chassis Card Description Version Status Card 4 Channel Relay 1.0.0 Card 8 Channel Binary 1.0.0 Card 4 Channel Universal Analog 1.0.0 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 144 Card 8 Channel Digital Temperature 1.0.1 Card 4 Channel Relay 1.0.0 Card 8 Channel Binary 1.0.0 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 145: Bye

    Related Commands: none Example: Command<1>: BYE User #1 logged off at 02:42:51 NO CARRIER Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 146: Channels

    USER NO. 1 CHANNELS: A0001 PBD02 LOAD 11 PCFD00 D1 LDA B0001 1231H1 HIGH VOLTAGE ALARM R0001 TANDEM 5TH FL MAJOR ALARM END OF USER NO. 1 CHANNELS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 147: Class

    Comments: If no description was previously entered, "none" is displayed after the alarm class number. Notes: none Related Commands: SET CLASS Example: Command<2>: CLASS Programmable Alarm Classifications K1.MINOR K2.MAJOR K3.none K4.FACIL K5.none K6.none K7.none K8.ENGR Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 148: Clr

    Notes: Only the commands that the user has access to are listed. Related Commands: See Example below. Example: Command<6>: clr Clear what: EVENTS MAIL POWER PROGRAM STATS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 149: Clr Aco

    Notes: Any user entering this command will have his name and this action recorded in the event log. Related Commands: ACO, SET ACO Example: Command<4>: CLR ACO No alarms are cutoff. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 150: Clr Events

    Also, after the log is cleared, a new entry will be made for the user who just cleared it. Notes: none Related Commands: EVENTS Example: Command<6>: CLR EVENTS Clear Event Log (Y or N)? Log cleared ! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 151: Clr Led

    Once the LED is cleared, a user phone report or Email message would occur. Any user entering this command will have his name and this action recorded in the event log. Related Commands: SET LED Example: Command<5>: CLR LED Clear LED: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 152: Clr Log

    Note that this command will also generate an entry in the event log. Example: Command<4>: CLR LOG Clear Alarm Log (Y or N): Y Log cleared. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 153: Clr Mail

    Line 2: THE DIESEL IS WORKING GREAT. Line 3: THANKS FOR YOUR HELP. Send To: 1 Read By: 3 Clear this mail (Y or N) ? y Mailed cleared! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 154: Clr Power

    Available only if the Power Metering software option is installed. Related Commands: POWER Example: Command<4>: CLR POWER Power Stats cleared. ___________________________________________________________________________________ Command<4>: CLR POWER 1 Power Stats cleared. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 155: Clr Program

    Related Commands: none Example: Command<5>: CLR PROG Which channel? R0001 CONTROL PROGRAM: R0001=B0001 Clear program line for channel R0001? (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 156: Clr Rly

    "Illegal request, not configured to access this channel". Related Commands: SET RLY Example: Command<5>: CLR RLY Clear Relay: 0003 Clear Relay: 0004 Clear Relay: 0064 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 157: Clr Stats

    Example: Command<4>: clr stats Reset all channel stats (Y or N): Y Statistics are cleared. ___________________________________________________________________________________ Command<6>: clr stats ? CLR STATS <tn> clear channel statistics Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 158: Clr Stats Daily

    Related Commands: STATS, STATS DAILY, STATS WEEKLY, STATS CHANNELS, SET STATS CHANNELS, CLR STATS, CLR STATS WEEKLY Example: Command<4>: clr stats daily Daily Statistics cleared! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 159: Clr Stats Weekly

    Related Commands: STATS, STATS DAILY, STATS WEEKLY, STATS CHANNELS, SET STATS CHANNELS, CLR STATS, CLR STATS DAILY Example: Command<4>: clr stats weekly Weekly Statistics cleared! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 160: Cmd

    Command 1 name: LOADS Command 1 access level: 1 Command 1 line 1: SCAN RECTIFIER Command 1 line 2: SCAN LOAD Command 1 line 3: SCAN CURRENT Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 161: Com

    Notes: The data rate, parity, number of data bits, and number of stop bits are displayed in the order listed, separated by commas. Related Commands: SET COM Example: Command<6>: COM Local Comm Port Setup: 2400,n,8,1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 162: Config

    If a limit is changed when an alarm is active which deactivates the alarm condition, the alarm remains active in the alarm log and will not be shown as cleared. Also, no retired alarm notification will be sent. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 163 Transducer Type: Transducer Type (Shunt, Current, Voltage, Temp, or None): Shunt type: current info Shunt type (50mv or 100mv): Scale Factor: 100.0 Scale Factor: Monitor type: DCVOLTS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 164 THIS CURRENT IS HIGH Limit 3 Enabled: Yes Limit 3 Enabled (Y or N): Limit 3 Value: 50.0 Limit 3 Value: 500 Limit 3 Type: L Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 165 Act Rpt Pol Unit Off-Dly-On F0001 Function Channel 1 Volt Sub-access ID Montype Monfmt FUNCTION1 DCVOLTS LIMITS CONFIGURATION Limit / Name Class Condtype Ntfc Svef 70.00H HVA2 MAJOR TOOHIGH Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 166 Limit 2 Type: H Limit 2 Type is High or Low (H or L): Limit 2 Name: HVA1 Limit 2 Name: ABOVE 4200 Limit 2 Notification Code: MJ Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 167 Unit Text: AMPS Off Delay Time: 0s Off Delay Time: On Delay Time: 0s On Delay Time: 15 Save changes (Y or N): Y Enter Program Line: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 168 Command<5>: CONFIG L0001 LED CHANNEL CONFIGURATION AS OF 07:35:00 ON 01/01/01. Chan Description Act Alm Rpt Class Off-Dly-On L0001 LED Channel 1 Sub-access ID Ctrltype Condtype Ntfc Svef Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 169 Name: Binary Channel 3 Name: FIRE ALARM! Sub-access Identifier: BINARY3 Sub-access Identifier: RECT1 System Alarm Report mode: Y System Alarm Report mode (Y or N): Condition Type: LOW Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 170 Name: Energy Mngmt PCU1 Shunt = A0070 Energy Mngmt PCU1 Shunt = Rectifier ON when Standby ON (Y or N): Save changes (Y or N): Y Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 171: Connect

    Note that the Warning message is only displayed when using the LMS1000 modem port. Command<4>: CONNECT WARNING!!! ALARM REPORTS CANNOT BE PROCESSED WHILE GATEWAY SESSION IS ACTIVE GATEWAY port active Press <CTRL-C><CTRL-C> to exit <cursor> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 172 If the CONNECT command is issued from an established modem dial up session, and a modem report is pending, the following message is displayed: Report is pending. Cannot activate GATEWAY port. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 173: Dac Del

    PIN: [PIN#] Save Changes (Y or N): [Y|N] ___________________________________________________________________________________ ERROR: The entered PIN does not match the current value for DAC Code #[Code #]. CODE NOT CHANGED Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 174: Dac List

    Related Commands: DAC DEL, DAC SET, DAC SET LOCK OFF, DAC SET LOCK ON, DAC STATUS, LOCK, UNLOCK Example: Command <6>: DAC LIST User DAC001 4312 DAC002 1234 DAC003 1298 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 175: Dac Set

    Save Changes (Y or N): [Y|N] DAC Code #[Code #] has been added/changed with PIN [PIN#] ___________________________________________________________________________________ Command <6>: DAC ADD [User #] [PIN#] [User] has been added with PIN [PIN#] Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 176: Dac Set Lock Off

    Related Commands: DAC DEL, DAC LIST, DAC SET, DAC SET LOCK ON, DAC STATUS, LOCK, UNLOCK Example: Command <6>: DAC SET LOCK OFF DAC Lock is now Off Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 177: Dac Set Lock On

    Related Commands: DAC DEL, DAC LIST, DAC SET, DAC SET LOCK OFF, DAC STATUS, LOCK, UNLOCK Example: Command <6>: DAC SET LOCK ON DAC Lock is now On Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 178: Dac Status

    Command <6>: DAC STATUS Actual state is Open ___________________________________________________________________________________ Command <6>: DAC STATUS Actual state is Closed ___________________________________________________________________________________ Command <6>: DAC STATUS Actual state is Locked ? Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 179: Date

    Description: Displays the current day of the week, month, day, year, and time. Command Level: 1 Syntax: DATE Comments: none Notes: Related Commands: SET DATE Example: Command<1>: DATE Today is Monday 01/01/01 at 08:57:51. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 180: Download

    XMODEM and CRC checking. Related Commands: UPLOAD Example: Command<6>: DOWNLOAD DUMP using XMODEM Protocol with CRC error checking Waiting for 'C' - You have 1 minute! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 181: Download Tftp

    A separate TFTP client session must be started on the host to which the configuration file is transferred. Related Commands: UPLOAD TFTP Example: Command<6> : DOWNLOAD TFTP DOWNLOAD using TFTP Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 182: Download Tftp Nps

    Command<6> : DOWNLOAD TFTP NPS Preparing the system for configuration download via TFTP Retrieving NPS settings. Please wait. Begin TFTP File transfer. TFTP ERROR -- Timeout Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 183: Download Tftp Netsure

    Command<6> : DOWNLOAD TFTP NETSURE Preparing the system for configuration download via TFTP Retrieving NETSURE settings. Please wait. Begin TFTP File transfer. TFTP ERROR -- Timeout Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 184: Download Nps

    Command<6>: DOWNLOAD NPS Retrieving NPS settings DUMP using XMODEM Protocol with CRC error checking Waiting for 'C' - You have 1 minute! 9 blocks transmitted OK. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 185: Download Netsure

    Command<6>: DOWNLOAD NETSURE Retrieving NETSURE settings DUMP using XMODEM Protocol with CRC error checking Waiting for 'C' - You have 1 minute! 9 blocks transmitted OK. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 186: Eff

    VPS/NPS rectifiers/PCUs that are turned on by the energy management option, if any. Command Level: 1 Syntax: Comments: None Notes: Related Commands: none Example: Command<1>: eff RECTIFIER EFFICIENCY ROUTINE ACTIVE FOLLOWING RECTIFIERS TURNED ON 1,2,3,4,5,6 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 187: Events

    Power Metering stats cleared 06/03/09 03:03:04 User #7 F32 Power Meter stat cleared 06/03/09 03:02:51 Key code #121 validated 08/15/03 13:56:44 Invalid Key Code Entered 08/15/03 13:55:14 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 188 10/10/10 xx:xx:xx SMART NETSURE Num PCUs changed 10/10/10 xx:xx:xx SMART NETSURE ACO feature activated 10/10/10 xx:xx:xx SMART NETSURE Subsystem installed 10/10/10 xx:xx:xx SMART NETSURE Subsystem removed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 189 NETSURE PCUn custom message set 10/10/10 xx:xx:xx User #8 NETSURE MCA logon password set 10/10/10 xx:xx:xx User #8 NETSURE system uploaded 10/10/10 xx:xx:xx User #8 NETSURE settings uploaded Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 190: Help

    INFO <n> show information pages display the IP Network variables LIMITS list channel alarm limits list alarm log entries Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 191 NODE CONFIG <n> configure user information for a node NODE DELETE <n> remove a node NODE INITIO <n> reinitialize a node's I/O hardware configuration Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 192 SNMP TRAPs TRAPS PERSISTENT disable/Enable the system’s ability to send SNMP Persistent Alarm TRAPS or set the Persistent Alarms reporting interval Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 193 SET NETSURE SYSTEM COMPSLOPE set Digital Temperature Comp. Slope SET NETSURE SYSTEM COMPMAX set Digital Temp. Comp. Max voltage SET NETSURE SYSTEM COMPMIN set Digital Temp. Comp. Min voltage Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 194 ALARMS list active alarms ANSWER show number of rings before the system answers BATTERY BATTERY type commands BOARDS list installed boards logoff and hangup Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 195 CLR EVENTS clear event log CLR LED <n> turn LED off CLR LOG clear alarm log CLR MAIL clear your mail from memory Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 196 SET TIME <hh:mm:ss> set time where hh = hours, mm = minutes, ss = seconds SET TIMEOUT <n> set user timeout SET UNIT set unit name and number Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 197 A, B, F, G, L, R for Analog, Binary, Function, Group, LED or Relay Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 198: Help Netsure

    SCAN NETSURE SYSTEM list present status of system data SET NETSURE INTERFACE Enable/Disable VPS/NPS interface SET NETSURE LVD<n<t>> DISCONNECT set specified LVD disconnect voltage settings Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 199 SET NETSURE SUBSYSTEM OVRCURRENT set subsystem Overcurrent alarm UPLOAD NETSURE configure VPS/NPS Power System by uploading file using XMODEM protocol UPLOAD TFTP NETSURE configure VPS/NPS Power System by uploading Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 200 TFTP where: <> anything enclosed in brackets is optional is a valid number is A or B for VPS/NPS LVD settings Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 201: Info

    Notes: Each page consists of 20 lines, each line 79 characters in length. Related Commands: SET INFO Example: Command<1>: info INFORMATION PAGE #1 RECTIFIERS: RL200D50 RL400D50 (2) FUSES C.B. MAINTENANCE BATTERY DISCHARGE ON 01/01/01 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 202: Limits

    THIS CURRENT IS ABOVE 7000 AMPS 6000 H ABOVE 6000 MAJOR HIGH Condition Description THIS CURRENT IS ABOVE 6000 AMPS BELOW 500 MINOR Condition Description THIS CURRENT IS BELOW 500 AMPS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 203 VOLTAGE IS ABOVE 60 VOLTS 50.00L LVA1 MINOR Condition Description VOLTAGE IS BELOW 50 VOLTS 40.00L LVA2 MINOR TOOLOW Condition Description VOLTAGE IS BELOW 40 VOLTS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 204: Log

    MAJOR 11/01 11:09:00 11/01 12:09:21 B9015 NETSURE System Major MAJOR 11/01 12:09:06 00/00 00:00:00 B9016 NETSURE System Minor MINOR 11/01 12:08:06 00/00 00:00:00 ___________________________________________________________________________________ Command<1>: LOG Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 205 B0083 Main Chassis H/W Mismatch 05/13 13:22:53 05/13 13:23:35 B0082 Main Chassis H/W Failure 05/13 13:22:53 05/13 13:23:35 B0081 Self Diagnostics Error 05/13 13:22:53 05/13 13:23:35 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 206: Mail

    Mail from Office Manager posted 01/01/01 08:39:33. CHECK WATER LEVEL IN BATTERIES TODAY CALL ME @ 555-4645 IF ANY PROBLEMS Are you done with this mail? (Y or N) ? Y Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 207: Menu

    ALARMS NETSURE MCA ALARMS NETSURE PCU ALARMS NETSURE SHUNT ALARMS NETSURE SUBSYSTEM ALARMS NETSURE SYSTEM DOWNLOAD NETSURE PRCONFIG NETSURE PRCONFIG NETSURE INVENTORY PRCONFIG NETSURE SETTINGS SCAN NETSURE Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 208 MAIL MENU MODE NETWORK NODE OPTIONS PERIODS PHONE POWER PRCONFIG PROGRAM RATE REPORT SCAN SEQUENCE SNMP STATS STATUS TIME TIMEOUT TRAPS UNIT UPLOAD USERS Programmed Commands: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 209: Mode

    TL1 (over Ethernet) Software Option Installed Command<6>: MODE TL1 Mode: Telnet TCP Keepalive: Enabled Port: 2020 Session Timeout: 600 min Auto logon: Enabled Auto logon user: User #7 AID delimiter: Yes Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 210: Network

    Notes: Only the commands that the user has access to are listed. Related Commands: NETWORK INITIALIZE Example: Command<6>: NETWORK IO network is running. Which action? INITIALIZE Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 211: Network Initialize

    WARNING: This command will terminate all alarm processing of remote I/O Do you wish to continue? (YES or NO): yes Do you wish to delete associated channels? (Yes or No): yes Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 212 Deleting Relay channels………… Searching for new nodes Node# Name Spec. Number Ser.# Echelon Id # 58212190001 12346 1A2B3C4D5F6A 58212190001 12346 1A2B3C4D5F6B 58212190002 12347 1A2B3C4D5F6C 58212190002 12347 1A2B3C4D5F6D Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 213: Node

    Related Commands: NODE ADD, NODE CONFIG, NODE DELETE, NODE LIST, NODE REPLACE Example: Command<2>: NODE IO network is running. Which action? ADD CONFIG DELETE LIST REPLACE Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 214: Node Add

    Only displayed for a very short time after a reset on a new system. Related Commands: NODE CONFIG, NODE DELETE, NODE LIST, NODE REPLACE Example: Command<6>: NODE ADD IO network is running. Searching for new nodes Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 215 Add Channel: B1-4 Add Channel: Enter channel (e.g. A12 or A1-6) or D to display. Del Channel: A11 Del Channel: Configure another node? (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 216: Node Config

    Related Commands: NODE ADD, NODE DELETE, NODE LIST, NODE REPLACE Example: Command<6>: NODE CONFIG IO network is running. Node# Name Spec. Number Ser.# Echelon Id # 58212190001 12346 1A2B3C4D5F6A Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 217 R0201 Relay channel 0201 Add Channel: Enter channel (e.g. A12 or A1-6) or D to display. Del Channel: A10 Del Channel: Configure another node? (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 218: Node Delete

    Related Commands: NODE ADD, NODE CONFIG, NODE LIST, NODE REPLACE Example: Command<6>: NODE DELETE IO network is running. Node# Name Spec. Number Ser.# Echelon Id # 58212190001 12346 1A2B3C4D5F6A 58212190001 12346 1A2B3C4D5F6B 58212190002 12347 1A2B3C4D5F6C Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 219 Do you wish to continue? (YES or NO): yes Do you wish to delete node 02 channels? (Yes or No): yes Deleting Analog channels………… Deleting Binary channels………… Deleting Relay channels………… Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 220: Node Initio

    Or the number of a configured node shown below Node# Name Spec. Number Ser.# Echelon Id # midddut 58212190001 12346 1A2B3C4D5F6A 58212190001 12346 1A2B3C4D5F6B 58212190002 12347 1A2B3C4D5F6C 58212190002 12347 1A2B3C4D5F6D Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 221 Which node? : 5 Reinitializing node … ___________________________________________________________________________________ Command<6>: NODE INITIO 5 IO network is running. Reinitializing node … Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 222: Node List

    "NPS interface is running" is displayed when the NPS data is initialized. Otherwise, "NPS interface is initializing!" is displayed. Related Commands: NODE ADD, NODE CONFIG, NODE DELETE, NODE REPLACE Example: Command<2>: node list IO network is running. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 223 Echelon Id # ------------------------------------------------------------------------------- bottom 65535 00a015799100 Node# Name Spec.# Ser.# ----------------------------------------------------------------- NPS MCA node 1234567890123 3000000001 Node# Name Spec.# Ser.# Echelon Id # ------------------------------------------------------------------------------- 507606 00001 000581984200 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 224: Node Replace

    Only displayed for a very short time after a reset on a new system. Related Commands: NODE ADD, NODE CONFIG, NODE DELETE, NODE LIST Example: Command<6>: NODE REPLACE IO network is running. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 225 Select node to replace node 02?: X01 Storing node configuration Node# Name Spec. Number Ser.# Echelon Id # 58212190001 12346 1A2B3C4D5F6A 58212190001 12346 1A2B3C4D5F6B 58212190002 12347 1A2B3C4D5F6C 58212190002 12347 1A2B3C4D5F6D Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 226: Options

    AC & Diesel Sequencers not installed Energy Management installed,enabled Not Required Power Metering installed,enabled Not Required Door Access Controller not installed Gateway Port installed,enabled OEM1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 227: Periods

    TIME PERIOD No. 5 - FROM TIME PERIOD No. 6 - FROM 23:59:45 TO 00:00:00 TIME PERIOD No. 7 - FROM TIME PERIOD No. 8 - FROM Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 228: Phone

    Related Commands: SET PHONE Example: Command<1>: PHONE YOUR PHONE NUMBERS: Primary Phone: 5557685 Primary Phone Valid Days: 2-6 Primary Phone Valid Hours: 08-16 Alternate Phone: 5552423 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 229: Power

    04/26/98 THROUGH 04/29/98: 386.8 KWH Monthly 03/14/98 THROUGH 03/31/98: 1868.0 KWH 04/01/98 THROUGH 04/29/98: 3098.0 KWH F0003 POWER STATS: LOADB POWER Daily 04/28/98: 147.40 KWH 04/29/98: 79.85 KWH Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 230 BDFB POWER, 109.20 KWH, 59.17 KWH, 762.8 KWH, 386.8 KWH, 1868.0 KWH, 3098.0 KWH LOADB POWER, 147.40 KWH, 79.85 KWH, 1036.0 KWH, 524.0 KWH, 2583.0 KWH, 4233.0 KWH Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 231: Prconfig

    BINARY CHANNEL CONFIGURATION AS OF 07:38:21 ON 02/09/01. Chan Description Act Rpt Cont Class Off-Dly-On B0001 Binary Channel 1 Sub-access ID Condtype Ntfc Svef BINARY1 HIGH Condition Description Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 232 GROUP 2 CONFIGURATION: Group No. 2 ___________________________________________________________________________________ Command<2>: P A0001 ANALOG CHANNEL CONFIGURATION AS OF 07:01:03 ON 02/09/01. Chan Description Act Rpt Pol Scale 4-20 Unit Off-Dly-On Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 233 Command<2>: P E1 ENERGY MANAGEMENT CHANNEL CONFIGURATION AS OF 16:33:32 ON 09/11/01. Chan Description Act Capacity Sht RFA TR E0001 Energy Mngmt PCU1 100.0 A70 B84 --- Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 234: Prconfig Nps

    Related Commands: PRCONFIG, PRCONFIG NETSURE Example: Command<6>: PR NPS NPS POWER SYSTEM SETTINGS AS OF 14:21:32 ON 12/10/03. System Adjustment Setpoints Description Value Units Float Voltage 52.10 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 235 Description 01--02 Fuse Fuse 01-01 Load 03--06 Fuse Fuse 01-03 Load 07--12 Fuse Fuse 01-07 Load 13--20 Fuse Fuse 01-13 Load 21--24 Breaker Breaker 01-21 Load Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 236 Spec. Number Ser. # FW Ver. ------------------------------------------------------------------------ Bay Router 2-01: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX 509509 16843009 2.0.1.0 Dist. Panel 2-01: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX 509525 50462976 2.0.3.0 Positions Element Type Load Description Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 237 System distribution loads A and B are activated Float mode is active Power Share is inactive Alternate Current Limit is active , limiting @ 90% of output capacity ___________________________________________________________________________________ Command<6>: PR NPS SET Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 238 Spec. #: 1234567890123 S/N:-1294967295 Description Spec. Number Ser. # FW Ver. ------------------------------------------------------------------------ Bay Router 1-01: This is the ROUTER on the MCA BD 509478 2801621 1.0.1.0 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 239 01-04 This CAN I/O board is in loc 1-4 ABE SPEC# 524550 84082691 2.0.5.0 01-05 --- open --- 01-06 --- open --- 01-07 --- open --- Bay 2 - NPS Bay #2 Spec. #: XXXXXXXXXXXXX S/N:1482184792 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 240 02-07 --- open --- MCA: Description Spec. Number Ser. # FW Ver. ------------------------------------------------------------------------ this is the MCA 509478 2801621 1.0.0.14 System voltage is Averaged Temperature sensor reporting Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 241 02-05 --- open --- 02-06 --- open --- 02-07 --- open --- 02-08 --- open --- 02-09 --- open --- 02-10 --- open --- ___________________________________________________________________________________ Command<2>: PR NPS PCU Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 242 Fuse 01-01 Load 03--06 Fuse Fuse 01-03 Load 07--12 Fuse Fuse 01-07 Load 13--20 Fuse Fuse 01-13 Load 21--24 Breaker Breaker 01-21 Load Dist. Panel 1-02: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 243 This is Distribution Panel 03-03 DSM SPEC# 509525 50331648 2.0.3.0 Positions Element Type Load Description 25--30 Breaker Breaker 03-25 Load 31--36 Breaker Breaker 03-31 Load Dist. Panel 3-04: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 244 Breaker 01-25 Load 27--30 Breaker Breaker 01-27 Load 31--36 Breaker Breaker 01-31 Load 37--44 Breaker Breaker 01-37 Load 45--48 --- open --- PCU: -48 VDC Output Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 245 Description 01--02 Fuse Fuse 01-01 Load 03--06 Fuse Fuse 01-03 Load 07--12 Fuse Fuse 01-07 Load 13--20 Fuse Fuse 01-13 Load 21--24 Breaker Breaker 01-21 Load Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 246 NPS interface is running NPS EQUIPMENT INVENTORY AS OF 14:22:59 ON 12/10/03. Bay 1 - NPS Bay #1 Spec. #: 1234567890123 S/N:-1294967295 Description Spec. Number Ser. # FW Ver. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 247 01-04 This CAN I/O board is in loc 1-4 ABE SPEC# 524550 84082691 2.0.5.0 01-05 --- open --- 01-06 --- open --- 01-07 --- open --- Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 248 02-02 XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX RCB SPEC# 514348 67633409 2.0.4.0 02-03 XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX RCB SPEC# 514348 67698946 2.0.4.0 02-04 --- open --- 02-05 --- open --- 02-06 --- open --- 02-07 --- open --- Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 249: Prconfig Netsure

    Digital Temp. Comp. Max voltage 56.45 Digital Temp. Comp. Min voltage 49.50 Battery Current Limit 175.0 Amps Relay Test Time 45.00 seconds Test/Equalize Timeout 1.000 hours Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 250 System High Voltage Shutdown System Overcurrent Current limit System Calibrate Voltage NAG(ACO) Timer Temperature Compensation Voltage Subsystem High Voltage Alarm Subsystem Low Voltage Alarm Subsystem Calibrate Voltage Subsystem Overcurrent Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 251 Temperature Compensation Mode: None Description Spec. No. Ser.# Vers Vout Capacity A433800124 00.19.00 PCU01- A486526800 01.00.00 -48VDC PCU02- A486526800 01.00.00 -48VDC PCU03- A486526800 01.00.00 -48VDC PCU04- A486526800 01.00.00 -48VDC Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 252: Program

    Comments: The size occupied by the programs is also displayed. Notes: none Related Commands: SET PROGRAM Example: Command<2>: PROGRAM Control Programs ARE Running Control Programs: R0001=b0001 L0001=a0001 L0002=b0009 Program Space is 1.7% full. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 253: Rate

    A0003 PBD02 LOAD 13 300.0 FUSE SIZE 44.0 , 29% 44.2 , 29% A0003 PBD02 LOAD 13 200.0 FUSE CAP. 44.0 , 44% 44.2 , 44% Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 254: Report

    Related Commands: SET REPORT Example: Command<6>: REPORT System Alarm Report mode: Single User Calling Sequence: 6 5 4 Retry Time: 10m Auto-logoff Time: 60sec Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 255: Scan

    +20.0 Amps A0003 Analog Channel 3 Amps L - below 500 MINOR A0004 Analog Channel 4 +19.9 Amps BINARY CHANNEL STATUS AS OF 15:19:02 ON 11/01/01. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 256 Description Status Alarm Status / Class R0001 Relay Channel 1 On ,Pg active MINOR R0002 Relay Channel 2 R0003 Relay Channel 3 R0004 Relay Channel 4 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 257: Scan Netsure

    A9001 NETSURE System Voltage +50.3 [None] A9002 NETSURE System Current +800 Amps [None/Overcurrent] A9006 NETSURE Shunt01 Current +200 Amps [None/Fail] A9007 NETSURE Shunt02 Current +200 Amps [None/Fail] Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 258 Amps [None/Fail] A9045 PCU20 Current +100 Amps [None/Fail] The following is displayed only if Battery Shunt PODs installed: NETSURE BATTERY STATUS AS OF 08:25:10 ON 05/04/06. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 259 B9009 NETSURE PCU Emergency Stop [None/Active] B9024 NETSURE PCU High AC Line [None/Active] B9010 NETSURE System Fuse [None/Active] B9011 NETSURE All AC Off [None/Active] B9014 NETSURE LVDs Inhibited [None/Active] Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 260 [inhibited/failed/active/inactive] LVD 1B [inhibited/failed/active/inactive] LVD 2A [inhibited/failed/active/inactive] LVD 2B [inhibited/failed/active/inactive] LVD 3A [inhibited/failed/active/inactive] LVD 3B [inhibited/failed/active/inactive] The following is displayed only for active potentiometer controlled LVDs: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 261 Amps [None/Fail] A9031 PCU06 Current +100 Amps [None/Fail] A9034 PCU09 Current +100 Amps [None/Fail] A9037 PCU12 Current +100 Amps [None/Fail] A9045 PCU20 Current +100 Amps [None/Fail] Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 262: Sequence

    AC Fail/Transfer Input = B0001 Input type: AC Fail Standby Sequencer: Standby On/Proper Operate Input = B0001 Standby Start Delay: 15sec Sequencer Failsafe time: 100sec AC Restoration Qualification time: 100sec Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 263: Set

    Command<6>: set Set what: ANSWER CHANNELS CLASS DATE DEFAULTS EMAIL GATEWAY INFO LIMITS MAIL PERIODS PROFILE PHONE PROGRAM REPORT SEQUENCE STATS STATUS SYSTEM TIME TIMEOUT UNIT USERS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 264: Set Aco

    A0001 Analog Channel 1 +20.1 Amps 20.0 H - Hi Limit 2 MAJOR Chan Description Status Alarm Status / Class B0001 Binary Channel 1 active MINOR Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 265: Set Aid

    Now, to associate the sub-entities (each rectifier, each battery string, etc.) to the entity (the power plant), you configure the access identifier to include all LMS1000 channels monitoring this entity and any sub-entity contained within. Related Commands: AID Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 266 Name: Type: Enter channel (eg. A0012 or A0001-6) or D to display. Add channel: Enter channel (eg. A0012 or A0001-6) or D to display. Del channel: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 267: Set Answer

    Notes: The number of rings defaults to 1 but can be programmed for up to 99 rings. Related Commands: ANSWER Example: Command<5>: SET ANSWER Rings before answer: 1 Enter New #: Rings before answer: 1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 268: Set Channels

    Add Channel: A0013 Channel does not exist! Add Channel: A0064 Add Channel: Enter channel (eg. A0012 or A0001-0006) or D to display. Del Channel: A0064 Del Channel: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 269: Set Class

    Related Commands: CLASS Example: Command<6>: SET CLASS Programmable Alarm Classifications K1.MINOR K2.MAJOR K3.none K4.CLAS4 K5.none K6.none K7.none K8.ENGR Which alarm class(K1-8) ? 4 Alarm Class Name: CLAS4 FACIL Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 270: Set Cmd

    Command 1 line 1: SCAN A Command 1 line 2: Command 1 line 2: STATS A Command 1 line 3: Command 1 line 3: Command 1 line 4: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 271 Command 1 line 5: Command 1 line 6: Command 1 line 6: Command 1 line 7: Command 1 line 7: Command 1 line 8: Command 1 line 8: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 272: Set Com

    Default setting shown in underlined type. Notes: none Related Commands: COM Example: Command<6>: SET COM Local Comm Port Setup:2400,n,8,1 Enter new setup:19200 Re-initialize Port (Y or N):Y Local Comm Port Setup:19200,n,8,1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 273: Set Date

    Any user changing the date will have his name and this action recorded in the event log. Related Commands: DATE Example: Command<3>: SET DATE Date is 01/16/01. Use Format MM/DD/YY Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 274: Set Defaults

    Execution of this command will DESTROY ALL SYSTEM CONFIGURATIONS and could result in ALARM CONDITIONS !! Do you wish to set defaults(YES or No)? N Defaults NOT set Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 275 ALARM CONDITIONS !! Do you wish to set defaults(YES or No)? yes Setting system defaults Initializing Analog I/O card hardware Defaults set. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 276: Set Eff

    RECTIFIER EFFICIENCY ROUTINE (Y or N): y ___________________________________________________________________________________ Command<5>: set eff RECTIFIER EFFICIENCY ROUTINE DISABLED Plant Voltage Input = A0001 RECTIFIER EFFICIENCY ROUTINE (Y or N): y Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 277: Set Email

    Command<6>: set email Primary DNS Address : 0.0.0.0 Secondary DNS Address : 0.0.0.0 Local SMTP Server Address : 0.0.0.0 Email Return Address : Enter Primary DNS Address : Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 278: Set Gateway

    If the Gateway port is in use by another User, the requesting User is prompted as follows: Unable to change settings – port in use by another user. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 279: Set Info

    Line 10: Line 11: Line 12: MAINTENANCE Line 13: BATTERY DISCHARGE ON 06/19/96 Line 14: Line 15: Line 16: Line 17: Line 18: Line 19: Line 20: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 280: Set Led

    MCA display when the LED is active. Related Commands: CLR LED Example: Command<5>: SET LED Set LED (1 - 8): 3 Set LED (1 - 8): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 281: Set Limits

    VOLTAGE IS TOO LOW Alarm Limit Mode: N Alarm Limit Mode (N or B) ? N Limit 1 Enabled: Yes Limit 1 Enabled (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 282 Limit 3 Service Effect Code: SA Limit 3 Service Effect Code: Limit 3 Alarm Class Number: 0 Condition Type: LOW Condition Type: Limit 3 Condition Description: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 283 Limit 1 Type is High or Low (H or L): Limit 1 Name: ABOVE 5000 Limit 1 Name: Limit 1 Notification Code: CR Limit 1 Notification Code: Limit 1 Service Effect Code: SA Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 284 Limit 4 Value: 50.00 Limit 4 Value: Limit 4 Type: L Limit 4 Type is High or Low (H or L): Limit 4 Name: BELOW 50 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 285 Limit 4 Service Effect Code: Limit 4 Alarm Class Number: 0 Condition Type: TOOLOW Condition Type: Limit 4 Condition Description: CURRENT IS TOO LOW Condition Description: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 286: Set Mail

    User 4 - Jerry Collins User 5 - Jim Smith User 6 - Joe Jones User 7 - Bob Smith User 8 - Maintenance Personnel To Users: 3 5 6 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 287: Set Mode

    Address/Phone Number: The PRIMARY PHONE NUMBER attribute of the user's configuration provides the network address to the system for TL1 autonomous messages. The DIRECT mode of operation transmits the Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 288 Auto logon (Y or N): Auto logon user: AID Delimiter (Y or N): Save changes (Y or N): Must issue a hardware reset for changes to take effect Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 289: Set Nps

    Set What: SYSTEM MESSAGE PASSWORD CANIO ? pcu Which PCU (bay#-pcu#)? 01-01 Turn PCU 01-01 ON or OFF? off PCU 01-01 set OFF Command<6>: set NPS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 290 ___________________________________________________________________________________ Command<6>: set NPS Set What: SYSTEM MESSAGE PASSWORD CANIO ? canio Which CAN I/O board (bay#-board#)? 01-04 What CAN I/O board parameter: LOADTYPE SCALE BINARY Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 291: Set Nps Canio

    Set scale for INPUT or OUTPUT? output Enter full scale Amps (100 - 20000): 100 CAN I/O board 01-04 Output scale set ___________________________________________________________________________________ Command<6>: set NPS canio Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 292 Binary Input #2 set to alarm on contact CLOSED Set alarm on contact OPEN or CLOSED? open Binary Input #2 set to alarm on contact OPEN Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 293: Set Nps Message Canio_Bd

    Enter 0 for CAN I/O board or 1-6 for individual I/O # 0 Custom message: This is CAN I/O board in loc 4-3 Custom message: Custom message NOT CHANGED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 294: Set Nps Message Distribution

    Enter 0 for DIST panel or 1-24 for panel element # 0 Custom message: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX Custom message: this is panel 1 in bay 2 Custom message CHANGED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 295: Set Nps Message Mca

    Custom message: this is the MCA Custom message CHANGED! ___________________________________________________________________________________ Command<6>: set NPS mes mca Custom message: this is the MCA Custom message: Custom message NOT CHANGED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 296: Set Nps Message Pcu

    Custom message: this is pcu 01-01 Custom message CHANGED! ___________________________________________________________________________________ Command<6>: set NPS mes Which custom message: ROUTER DISTRIBUTION RELAY_BD ? pcu Which Bay? 1 Feature not supported by PCU Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 297: Set Nps Message Relay

    Which message? Enter 0 for relay board or 1-6 for individual relay # 0 Custom message: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX Custom message: this is board 2 Custom message CHANGED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 298: Set Nps Message Router

    Notes: The custom message can be 20 characters, maximum. Related Commands: none Example: Command<6>: set NPS mes rou Which bay #? 02 Custom message: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX Custom message: this is bay 2 Custom message CHANGED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 299: Set Nps Password

    Enter new password: Re-enter new password: New password not accepted ___________________________________________________________________________________ Command<6>: set NPS pass Enter current MCA password: Enter new password: Re-enter new password: New password accepted Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 300: Set Nps Pcu

    582140001 Power System Command<6>: set NPS pcu Which bay? 1 Which PCU 2070500016 2070500001 ? 2070500016 Turn PCU 01-2070500016 ON or OFF? on PCU 01-2070500016 set ON Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 301: Set Nps System Batondisch

    Related Commands: none Example: Command<5>: set NPS sys bat Battery on Discharge Alarm: 51.00 VDC Battery on Discharge Alarm: 51.1 New Battery on Discharge Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 302: Set Nps System Capaltcurlimit

    Related Commands: none Example: Command<6>: SET NPS SYSTEM CAPALTCURLIMIT Engine Current Limit Capacity: 0 % Engine Current Limit Capacity: 90 New Engine Current Limit Capacity Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 303: Set Nps System Curlimit

    Notes: The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: set NPS sys cur Plant Current Limit: 5600 Amps Plant Current Limit: 5700 New Plant Current Limit Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 304: Set Nps System Eqmultiplier

    Not Changed! Related Commands: none Example: Command<6>: set NPS sys eq Auto Equalize Time Multiplier: 0 Auto Equalize Time Multiplier: 1 New Auto Equalize Time Multiplier Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 305: Set Nps System Fltvolt

    The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: set NPS flt Float Voltage: 52.08 VDC Float Voltage: 52.1 New Float Voltage Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 306: Set Nps System Hi1Tempalm

    High Temperature #1 Alarm NOT CHANGED! ___________________________________________________________________________________ Command<5>: set NPS sys hi1 High Temperature #1 Alarm: 100 DegC High Temperature #1 Alarm: 99 New High Temperature #1 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 307: Set Nps System Hi2Tempalm

    High Temperature #2 Alarm NOT CHANGED! ___________________________________________________________________________________ Command<5>: set NPS sys hi2 High Temperature #2 Alarm: 100 DegC High Temperature #2 Alarm: 99 New High Temperature #2 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 308: Set Nps System Hivltalm1

    Related Commands: none Example: Command<5>: set NPS sys hivltalm1 High Voltage #1 Alarm: 55.50 VDC High Voltage #1 Alarm: 55.6 New High Voltage #1 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 309: Set Nps System Hivltalm2

    Related Commands: none Example: Command<5>: set NPS sys hivltalm2 High Voltage #2 Alarm: 56.50 VDC High Voltage #2 Alarm: 56.6 New High Voltage #2 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 310: Set Nps System Hvs

    The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: set NPS sys hvs High Voltage Shutdown: 57.50 VDC High Voltage Shutdown: 57.6 New High Voltage Shutdown Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 311: Set Nps System Loadacurrent

    Related Commands: none Example: Command<5>: set NPS sys loada A Load Overcurrent Alarm: 2500 Amps A Load Overcurrent Alarm: 2600 New A Load Overcurrent Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 312: Set Nps System Loadbcurrent

    Related Commands: none Example: Command<5>: set NPS sys loadb B Load Overcurrent Alarm: 2000 Amps B Load Overcurrent Alarm: 2100 New B Load Overcurrent Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 313: Set Nps System Loadcurrent

    Related Commands: none Example: Command<5>: set NPS sys loadc Total Load Overcurrent Alarm: 5000 Amps Total Load Overcurrent Alarm: 5100 New Total Load Overcurrent Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 314: Set Nps System Low1Tempalm

    Related Commands: none Example: Command<5>: set NPS sys low1 Low Temperature #1 Alarm: -50 DegC Low Temperature #1 Alarm: -49 New Low Temperature #1 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 315: Set Nps System Low2Tempalm

    Related Commands: none Example: Command<5>: set NPS sys low2 Low Temperature #2 Alarm: -50 DegC Low Temperature #2 Alarm: -49 New Low Temperature #2 Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 316: Set Nps System Nagtimer

    The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: SET NPS SYS PWRSHARECAP Power Share Capacity: 80 % Power Share Capacity: 70 New Power Share Capacity Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 317: Set Nps System Rlyofftest

    Command<6>: set NPS sys rlyoff Relay Function 1 test is active Remaining test time: 30 Stop Relay Function Test? (Y or N): y Relay Test Stopped! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 318: Set Nps System Rlyontest

    Start Relay Function Test? (Y or N): Y Relay Test Started! ___________________________________________________________________________________ Command<6>: set NPS sys rlyon Relay Function 1 test is active Remaining test time: 43 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 319: Set Nps System Rlytsttime

    Notes: The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<5>: set NPS sys rly Relay Test Time: 10 sec. Relay Test Time: 20 New Relay Test Time Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 320: Set Nps System Seqdelay

    Related Commands: none Example: Command<6>: SET NPS SYSTEM SEQDELAY PCU Sequencing Delay Time: 0 sec. PCU Sequencing Delay Time: 3 New PCU Sequencing Delay Time Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 321: Set Nps System Tempcompmax

    Maximum Temp. Compensation Voltage NOT CHANGED! ___________________________________________________________________________________ Command<6>: set NPS sys tempcompmax Maximum Temp. Compensation Voltage: 56.50 VDC Maximum Temp. Compensation Voltage: 55.9 New Maximum Temp. Compensation Voltage Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 322: Set Nps System Tempcompmin

    Related Commands: none Example: Command<6>: set NPS sys tempcompmin Minimum Temp. Compensation Voltage: 50.00 VDC Minimum Temp. Compensation Voltage: 50.05 New Minimum Temp. Compensation Voltage Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 323: Set Nps System Tempslope

    NOTE, ANYTHING THAT EVALUATES TO ZERO DEACTIVATE TC ___________________________________________________________________________________ Command<6>: set NPS sys temp Temperature Compensation Slope: 0.000 V/DegC Temperature Compensation Slope: 0.1 New Temperature Compensation Slope Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 324: Set Nps System Tsteqmode

    Test equalize mode is OFF ___________________________________________________________________________________ Command<6>: set NPS sys tsteqm on System is in float mode. Turn test equalize mode ON or OFF? on Test equalize mode is ON Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 325: Set Nps System Tsteqtime

    Notes: The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: set NPS sys tsteqt Manual Test/Equalize Time: 1 hrs. Manual Test/Equalize Time: 2 New Manual Test/Equalize Time Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 326: Set Nps System Tsteqvolt

    The following message is displayed if the setting was not accepted by the MCA. Not Changed! Related Commands: none Example: Command<6>: set NPS sys tst Test/Equalize Voltage: 52.00 VDC Test/Equalize Voltage: 52.1 New Test/Equalize Voltage Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 327: Set Nps System Updateinv

    Execution of this command could REMOVE NPS Bay, PCU, and Distribution Panel Configuration and could result in lost ALARM CONDITIONS!! Do you wish to update the MCA inventory? (YES or NO): no Command NOT ACCEPTED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 328: Set Nps System Usecelsius

    SE NP SY USEC Comments: none Notes: none Related Commands: none Example: Command<6>: set NPS sys usec Change MCA to use Celsius? (Y or N): y Change ACCEPTED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 329: Set Nps System Usefahrenheit

    SE NP SY USEF Comments: none Notes: none Related Commands: none Example: Command<6>: set NPS sys usef Change MCA to use Fahrenheit? (Y or N): y Change ACCEPTED! Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 330: Set Nps System Verylowvolt

    Related Commands: none Example: Command<5>: set NPS sys very Very Low Voltage Alarm: 47.00 VDC Very Low Voltage Alarm: 47.1 New Very Low Voltage Alarm Accepted. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 331: Set Periods

    Which Time Period (1 - 8) ? 1 Time Period No. 1 - FROM FROM time (hh:mm:ss) 08:15:00 time (hh:mm:ss) 16:00:00 Time Period No. 01 - FROM 08:15:00 TO 16:00:00 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 332: Set Phone

    Primary Phone Valid Hours: 00-23 Alternate Phone: Primary Phone: Primary Phone: Valid Times for Primary Phone From Day: From Day: Thru Day: Thru Day: From Hour: From Hour: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 333 Thru Hour: Thru Hour: Alternate Phone: Alternate Phone: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 334: Set Profile

    Command<6>: set profile 1. DGU 2. SMU 3. WB57 4. Custom2 5. Custom3 6. Custom4 Select a profile(1-6): 4 Device type: Custom2 Enter Device type: ENGMON Logon prompt: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 335 Save changes (Y or N): y Selecting a profile number that is not valid results in the following error message. Command<6>: SET PROFILE 9 Invalid device type specified Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 336: Set Program

    L, R, or F are valid. Related Commands: PROGRAM Example: Command<5>: SET PROGRAM Which Channel ? R0003 Control Program: None Enter Program Line: R0003=A0005&B0001&P1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 337: Set Report

    User Calling Sequence: 6 5 4 1 Retry Time: 10m Auto-logoff Time: 60sec System Alarm Report mode: Continuous User Calling Sequence: 6 5 4 1 Retry Time: 10m Auto-logoff Time: 60sec Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 338: Set Rly

    Notes: Any user using the SET RLY command will have his name and this action recorded in the event log. The relay can be released using the command CLR RLY. Related Commands: CLR RLY Example: Command<6>: SET RLY Set Relay: 0005 Set Relay: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 339: Set Sequence

    Standby Sequencer on (Y or N): y Standby On/Proper Operate Input = B1 Standby Start Delay: 15 Standby Start Delay: Sequencer Failsafe time: 60 Sequencer Failsafe time: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 340 AC Restoration Qualification time: 0 AC Restoration Qualification time: Save changes (Y or N): RECTIFIER SEQUENCING ROUTINES (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 341: Set Stats Channels

    <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc> where: <tnncc> is the channel identifier by type (‘t’), node number (‘nn’), and channel number (‘cc’). Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 342: Set Status

    Pg 12: 5: B Pg 13: 6: B1 Pg 14: 7: B2 Pg 15: 8: B3 Pg 16: Which page (1-16) ? 2 Pg 2 name: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 343 Pg 2 line 2: Pg 2 line 2: Pg 2 line 3: Pg 2 line 3: A5 Pg 2 line 4: Pg 2 line 4: A6 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 344: Set System

    Unit Name: Central Office - Unit #1 System Identifier(SID): Rings before answer: 1 Enter New #: Rings before answer: 1 USER NO. 1 CONFIGURATION Name: User #1 Occurred Alarm Report: No Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 345 From Day: 1 From Day: Thru Day: 7 Thru Day: From Hour: 0 From Hour: Thru Hour: 23 Thru Hour: Alternate Phone: Alternate Phone: Primary E-mail: Primary E-mail: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 346 Daily Report Command: Report Device: Modem Daily Report Time: Report Retry Time: 15m Primary Phone: Primary E-mail: Primary Phone Valid Days: 1-7 Primary Phone Valid Hours: 00-23 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 347 Alternate E-mail: Report Device: Modem Report Device (Modem, Ethernet, or X25): Report Mode: Off Report Mode (Off, Modem, E-mail): Report Retry Time: 15 Report Retry Time: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 348 Auto-logoff Time: 60sec System Alarm Report mode: User Calling Sequence: Retry Time: Auto-logoff Time: System Alarm Report mode: Off User Calling Sequence: Retry Time: 10m Auto-logoff Time: 60sec Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 349: Set Time

    Any user changing the time will have his name and this action recorded in the event log. Related Commands: TIME Example: Command<3>: SET TIME Time is 02:29:04. Use Format HH:MM:SS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 350: Set Timeout

    The TL1 port has a session timeout feature which operates independently from the user timeout feature. Related Commands: TIMEOUT Example: Command<6>: SET TIMEOUT User timeout: 300 seconds. Enter new user timeout: User timeout: 300 seconds. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 351: Set Unit

    Unit Pager Code: Pager Delay: Unit Name: Lorain Engineering Unit #1 System Identifier (SID): Unit Header: THIS IS THE UNIT HEADER Unit Pager Code: 216-288-1122# Pager Delay: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 352: Set Users

    Name: User #1 Occurred Alarm Report: No Password: 1 Retired Alarm Report: No Access Level: 1 Persistent Alarm Report: No Callback: No Persistent Alarm Report Period: 0m Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 353 Thru Day: 7 Thru Day: From Hour: 0 From Hour: Thru Hour: 23 Thru Hour: Alternate Phone: Alternate Phone: Primary E-mail: Primary E-mail: Alternate E-mail: Alternate E-mail: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 354 Stand-alone: Voltage channel - none ; Current channel - none Related Commands: none Example: Command<6>: SET VI Plant Voltage: Plant Voltage: A9001 Plant Current: Plant Current: A9002 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 355: Set Netsure

    What Subsystem parameter: HIVALM LVALM OVRCURRENT CALVOLT FACTORYCAL ___________________________________________________________________________________ Command<6>: SET N LVD What LVD setting: RECONNECT DISCONNECT ?DISCONNECT Which LVD PANEL(1-3)?1 Which LVD circuit(A or B)?A ___________________________________________________________________________________ Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 356 Command<6>: SET N INTERFACE Netsure Power System interface is DISABLED Do you wish to activate Netsure Power System interface (Y or N): y Netsure Power System interface is ACTIVE Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 357: Set Netsure Lvd Disconnect

    Which LVD circuit(A or B)? B LVD3B Disconnect voltage setting: 42.00 VDC LVD3B Disconnect voltage setting: ___________________________________________________________________________________ Command<6>: SET N LVD2B DISCONNECT No digitally controlled LVDs installed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 358: Set Netsure Lvd Forceconn

    Which LVD board (1-3)? 1 Which circuit (A or B)? A LVD1A is not disconnected Invalid LVD board specified Invalid circuit specified LVD1A is connected LVD1 not installed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 359: Set Netsure Lvd Reconnect

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N LVD RECONNECT LVD Reconnect Voltage: 49.00 VDC LVD Reconnect Voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 360: Set Netsure Message Mca

    Comments: The current message is displayed, followed by a prompt to enter a new message. Notes: The custom message can be 20 characters, maximum. Related Commands: none Example: Command<6>: SET N MESSAGE MCA Custom message: Custom message: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 361: Set Netsure Message Pcu

    Comments: The current message is displayed, followed by a prompt to enter a new message. Notes: The custom message can be 20 characters, maximum. Related Commands: none Example: Command<6>: SET N MESSAGE PCU1 Custom message: Custom message: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 362: Set Netsure Password

    VPS/NPS access via the LMS1000. Netsure SMART/MCA communications error Related Commands: none Example: Command<6>: SET N PASSWORD Enter current MCA password: Enter new password: Re-enter new password: New password accepted Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 363: Set Netsure Pcu Fanspeed

    Notes: None Related Commands: none Example: Command<6>: SET N PCU03 FANSPEED PCU Fan Speed is Fast Set PCU Fan Speed Slow (Y or N): N Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 364: Set Netsure Pcu Loadshare

    Notes: None Related Commands: none Example: Command<6>: SET N PCU03 LOADSHARE PCU Load Share Alarm is On Turn PCU Load Share Alarm Off (Y or N): N Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 365: Set Netsure Pcu State

    Comments: The current state (on or off) of the PCU is displayed, followed by a prompt to change the PCU state. Notes: None Related Commands: none Example: Command<6>: SET N PCU03 STATE PCU03 is Off Turn PCU03 On (Y or N): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 366: Set Netsure Pcu Totalslots

    NETSURE SYSTEM 100APLACES, SET NETSURE SYSTEM 200APLACES Example: Command<6>: SET N PCU03 TOTALSLOTS Enter PCU output current (25, 50, 100, 200): 25 Total 25A Places: 16 Total 25A Places: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 367: Set Netsure Subsystem Calvolt

    The following message is displayed if a subsystem is not installed. No Subsystem Installed Related Commands: none Example: Command<6>: SET N SUBSYSTEM CALVOLT Subsystem Calibrate Voltage: 27.60 VDC Subsystem Calibrate Voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 368: Set Netsure Subsystem Factorycal

    Notes: The following message is displayed if a subsystem is not installed. No Subsystem Installed Related Commands: none Example: Command<6>: SET N SUBSYSTEM FACTORYCAL Subsystem calibrate voltage set to Factory default setting. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 369: Set Netsure Subsystem Hivalm

    The following message is displayed if a subsystem is not installed. No Subsystem Installed Related Commands: none Example: Command<5>: SET N SUBSYSTEM HIVALM Subsystem High Voltage Alarm: 28.00 VDC Subsystem High Voltage Alarm: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 370: Set Netsure Subsystem Lvalm

    The following message is displayed if a subsystem is not installed. No Subsystem Installed Related Commands: none Example: Command<5>: SET N SUBSYSTEM LVALM Subsystem Low Voltage Alarm: 27.00 VDC Subsystem Low Voltage Alarm: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 371: Set Netsure Subsystem Ovrcurrent

    The following message is displayed if a subsystem is not installed. No Subsystem Installed Related Commands: none Example: Command<5>: SET N SUBSYSTEM OVRCURRENT Subsystem Overcurrent: 1800 Amps Subsystem Overcurrent: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 372: Set Netsure System 25Aplaces

    Power system did not accept the new value, setting remains unchanged. Related Commands: SET NETSURE PCU TOTALSLOTS Example: Command<6>: SET N SYS 25APLACES Total 25A Places: 0 Total 25A Places: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 373: Set Netsure System 50Aplaces

    Power system did not accept the new value, setting remains unchanged. Related Commands: SET NETSURE PCU TOTALSLOTS Example: Command<6>: SET N SYS 50APLACES Total 50A Places: 0 Total 50A Places: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 374: Set Netsure System 100Aplaces

    Power system did not accept the new value, setting remains unchanged. Related Commands: SET NETSURE PCU TOTALSLOTS Example: Command<6>: SET N SYS 100APLACES Total 100A Places: 0 Total 100A Places: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 375: Set Netsure System 200Aplaces

    Power system did not accept the new value, setting remains unchanged. Related Commands: SET NETSURE PCU TOTALSLOTS Example: Command<6>: SET N SYS 200APLACES Total 200A Places: 0 Total 200A Places: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 376: Set Netsure System 50%Batondisch

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET N SYSTEM 50%BATONDISCH System 50% Battery On Discharge: System 50% Battery On Discharge: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 377: Set Netsure System Autoeqmult

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET NETSURE SYSTEM AUTOEQMULT Auto Equalize Multiplier: 0 Auto Equalize Multiplier: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 378: Set Netsure System Batondisch

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET N SYSTEM BATONDISCH System Battery On Discharge: 51.00 VDC System Battery On Discharge: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 379: Set Netsure System Battcurlim

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET NETSURE SYSTEM BATTCURLIM Battery Current Limit: 275.0 Amps Battery Current Limit: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 380: Set Netsure System Battovrcur

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET NETSURE SYSTEM BATTOVRCUR Battery Overcurrent: 2000 Amps Battery Overcurrent: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 381: Set Netsure System Calvolt

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N SYSTEM CALVOLT System calibrate voltage: 50.48 VDC System calibrate voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 382: Set Netsure System Compmax

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: set netsure system compmax Digital Temp. Comp. Max voltage: 56.50 VDC Digital Temp. Comp. Max voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 383: Set Netsure System Compmin

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET NETSURE SYSTEM COMPMIN Digital Temp. Comp. Min voltage: 50.00 VDC Digital Temp. Comp. Min voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 384: Set Netsure System Compslope

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET NETSURE SYSTEM COMPLSLOPE Digital Temp. Comp. Slope: 0.000 V/DEGC Digital Temp. Comp. Slope: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...

  • Page 385: Set Netsure System Compsource

    Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N SYSTEM COMPSOURCE Digital Temp. Comp. Source: Highest Digital Temp. Comp. Source(Highest, Averaged, or Probe1): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 386 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N SYSTEM CURLIMIT Current limit: 500 Amps Current limit: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 387 SET NETSURE SYSTEM FACTORYCAL SE N SY FACTORY Comments: None Notes: None Related Commands: none Example: Command<6>: SET N SYSTEM FACTORYCAL System calibrate voltage set to Factory default setting. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 388 The following message is displayed if the setting was not accepted by the MCA. Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N SYSTEM FLTVOLT Float voltage: Float voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 389 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET N SYSTEM HIVLTALM1 System High Voltage 1 Alarm: 50.00 VDC System High Voltage 1 Alarm: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 390 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET N SYSTEM HIVLTALM2 System High Voltage 2 Alarm: 53.00 VDC System High Voltage 2 Alarm: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 391 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET N SYSTEM HVS System How Voltage Shutdown: 59.50 VDC System How Voltage Shutdown: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 392 SET NETSURE SYSTEM INVENTORY SE N SY INV Comments: None Notes: None Related Commands: none Example: Command<6>: SET N SYSTEM INVENTORY Equipment inventory has been reset Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 393 Comments: The current operating mode is displayed, followed by a prompt to change the operating mode. Notes: None Related Commands: none Example: Command<6>: SET N SYSTEM MODE System Mode: Float System Mode (Float or TestEq): Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 394 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<4>: SET N SYSTEM NAGTIMER NAG (ACO) Timer: 5 minutes NAG (ACO) Timer: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 395 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET N SYSTEM OVRCURRENT System Overcurrent: 2000 Amps System Overcurrent: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 396 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<5>: SET NETSURE SYSTEM RLYTESTTIME Relay Test Time: 45 seconds Relay Test Time: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 397 Notes: The following message is displayed if the setting was not accepted by the MCA. Invalid value entered, request to update setting denied. Related Commands: none Example: Command<6>: SET N SYSTEM TEMPCOMP Temperature compensation Voltage: 48.09 VDC Temperature compensation Voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 398 Command<5>: SET NETSURE SYSTEM TEMPHIGH Which Temperature Probe (1-8)? 1 Temperature Probe #1 not installed Command<5>: SET NETSURE SYSTEM TEMPHIGH 1 Temperature Probe #1 not installed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 399 Example: Command<5>: SET NETSURE SYSTEM TEMPLOW Which Temperature Probe (1-8)? Temperature Probe #1 not installed Command<5>: SET NETSURE SYSTEM TEMPLOW 1 Temperature Probe #1 not installed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 400 Power system did not accept the new value, setting remains unchanged. Related Commands: none Example: Command<6>: SET NETSURE SYSTEM TSTEQTIME Test/Equalize Timeout: 1 hours Test/Equalize Timeout: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 401 The following message is displayed if the setting was not accepted by the MCA. Invalid value entered, request to update setting denied. Related Commands: none Example: Command<6>: SET N SYSTEM TSTEQVOLT Test/Equalize Voltage: 53.00 VDC Test/Equalize Voltage: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 402 Daily stats of all channels in stats channel group STATS WEEKLY Weekly stats of all channels in stats channel group STATS CHANNELS Show advanced statistics channel group Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 403 STATS <G> stats for all group channels STATS <G<n>> stats for specific group channels STATS <U> stats for all user channels Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 404 Related Commands: STATS, STATS DAILY, STATS WEEKLY, SET STATS CHANNELS, CLR STATS, CLR STATS DAILY, CLR STATS WEEKLY Example: Command<1>: stats channels Daily/Weekly Statistics channel list: <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc>, <tnncc> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 405 Command<1>: stats daily DAILY STATISTICS 10/25/2005 - Tuesday CHAN DESCRIPTION VALUE MEAS DATE/TIME ---------------------------------------------------------------------------- MAXIMUM PEAK A9001 System Voltage – Fifth Flr Plt 52.08 VDC 09/22/05 14:17:20 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 406 <n>'s channels STATS DAILY G<n> CSV stats of group <n>'s channels in comma-separated format Associated commands: CLR STATS DAILY , SET STATS CHANNELS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 407 The time/date stamp is the new hour. Related Commands: STATS, STATS DAILY, STATS CHANNELS, SET STATS CHANNELS, CLR STATS, CLR STATS DAILY, CLR STATS WEEKLY Example: Command<1>: stats weekly WEEKLY STATISTICS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 408 <n>'s channels STATS WEEKLY G<n> CSV stats of group <n>'s channels in comma-separated format Associated commands: CLR STATS WEEKLY , SET STATS CHANNELS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 409 Alarm3 Alarm4 A0001 PBD02 LOAD 11 +0.0 Amps A0002 PBD02 LOAD 12 +0.1 Amps A0003 PBD02 LOAD 13 +0.0 Amps A0004 PBD02 LOAD 14 +0.0 Amps Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 410 Description: Displays the current day of the week, month, day, year, and time. Command Level: 1 Syntax: TIME Comments: none Notes: none Related Commands: DATE Example: Command<1>: time Today is Thursday 06/19/01 at 15:34:21. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 411 Comments: At the end of the time interval, the system will terminate the communications session. Notes: none Related Commands: SET TIMEOUT Example: Command<2>: TIMEOUT User timeout: 300 seconds. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 412 Command<1>: UNIT LMS1000 v3.0.0 Unit Name: Central Office - Unit #1 System Identifier (SID): Unit Header: THIS IS THE UNIT HEADER Unit Pager Code: Pager Delay: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 413 Refer to the communications software package instruction manual for specific operating information. Related Commands: DOWNLOAD Example: Command<6>: UPLOAD UPLOAD using XMODEM Protocol with CRC error checking Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 414 Notes: A separate TFTP client session must be started on the host from which the configuration file is transferred. Related Commands: DOWNLOAD TFTP Example: Command<6> : UPLOAD TFTP UPLOAD using TFTP Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 415 Command<6> : UPLOAD TFTP NPS UPLOAD NPS Power System Custom Message Text Blocks (Y or N): UPLOAD using TFTP Could not transfer the configuration file “Timeout” Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 416 Command<6> : UPLOAD TFTP NETSURE UPLOAD NETSURE Power System Custom Message Text Blocks (Y or N): UPLOAD using TFTP Could not transfer the configuration file “Timeout” Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 417 Command<6>: UPLOAD NPS Upload NPS Power System Custom Message Text Blocks (Y or N)?n UPLOAD using XMODEM Protocol with CRC error checking 9 blocks received OK. Upload complete. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 418 Command<6>: UPLOAD NETSURE Upload NETSURE Power System Custom Message Text Blocks (Y or N)?n UPLOAD using XMODEM Protocol with CRC error checking 9 blocks received OK. Upload complete. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 419 Daily Report Command: Report Device: Modem Daily Report Time: Report Retry Time: 15m Primary Phone: Primary E-mail: Primary Phone Valid Days: 1-7 Primary Phone Valid Hours: 00-23 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 420 Primary Phone: Primary E-mail: Primary Phone Valid Days: 1-7 Primary Phone Valid Hours: 00-23 Alternate Phone: Alternate E-mail: USER NO. 4 CHANNELS: None . . . Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 421 NetSure 701/VPS: Voltage channel - A9001 ; Current channel - A9002 Stand-alone: Voltage channel - none ; Current channel - none Related Commands: none Example: Command<1>: VI Plant Voltage: A9001 Plant Current: A9002 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 422 IP NETWORKING COMMANDS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 423 The following page shows a sample command page that explains the format used for the commands listed in this section. Following the sample command page is an explanation of the conventions used, plus other information on using command options. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 424 Notes: This section discusses important points related to the use of the command, such as limitations or warnings. Related Commands: Lists related commands. Example: Shows one or more examples that illustrate how to use the command plus a typical screen display. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 425 Option Description Address nnn.nnn.nnn.nnn, where 0 ≤ nnn ≤ 255 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 426 Command<6> : IP IP Network Address : 216.32.74.51 IP Gateway Address : 216.32.74.1 IP Netmask : 255.255.255.0 Ethernet Address : 00:0C:0A:60:12:2C IP Authorized Hosts : 216.32.74.42 216.32.74.43 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 427 Notes: An IP address of 0.0.0.0 will prevent an Ethernet access to the unit. Related Commands: IP DELETE IP GATEWAY IP HOST IP NETMASK Example: Command<6> : IP ADDRESS 216.32.74.51 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 428 Notes: [address] must be a host currently on the list of authorized hosts. Related Commands: IP ADDRESS IP GATEWAY IP HOST IP NETMASK Example: Command<6> : IP DELETE 216.32.74.42 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 429 Notes: The gateway address must be a valid IP address and must not be 255.255.255.255. Related Commands: IP ADDRESS IP DELETE IP HOST IP NETMASK Example: Command<6> : IP GATEWAY 216.32.74.1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 430 255.255.255.255 are not permitted on the list. Notes: none Related Commands: IP ADDRESS IP DELETE IP GATEWAY IP NETMASK Example: Command<6> : IP HOST 216.32.74.42 IP host added. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 431 Comments: Enter the address in the format nnn.nnn.nnn.nnn, where 0 ≤ nnn ≤ 255. Notes: none Related Commands: IP ADDRESS IP DELETE IP GATEWAY IP HOST Example: Command<6> : IP NETMASK 255.255.255.0 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 432 SNMP COMMANDS Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 433 The following page shows a sample command page that explains the format used for the commands listed in this section. Following the sample command page is an explanation of the conventions used, plus other information on using command options. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 434 Notes: This section discusses important points related to the use of the command, such as limitations or warnings. Related Commands: Lists related commands. Example: Shows one or more examples that illustrate how to use the command plus a typical screen display. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 435 Option Description Address nnn.nnn.nnn.nnn, where 0 ≤ nnn ≤ 255 community name String of alpha/numeric characters. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 436 Comments: This displays the value of the SNMP variables, SNMP Enabled/Disabled, GET community string, and PUT community string. Notes: none Related Commands: SNMP GET SNMP OFF SNMP ON SNMP SET Example: Command<6> : SNMP SNMP:on GET:public SET:private Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 437 SNMP GET, GETNEXT, and GETBULK (in the case of SNMP 2c) operations. Notes: The string may not contain more than 128 characters. Related Commands: SNMP SNMP OFF SNMP ON SNMP SET Example: Command<6> : SNMP GET public Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 438 Notes: Prevents access to the system through the Ethernet port via an SNMP browser. Access to the system can be enabled by issuing the local command SNMP ON. Related Commands: SNMP SNMP GET SNMP ON SNMP SET Example: Command<6> : SNMP OFF Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 439 Notes: Enables access to the system through the Ethernet port via an SNMP browser. Access to the system can be disabled by issuing the local command SNMP OFF. Related Commands: SNMP SNMP GET SNMP OFF SNMP SET Example: Command<6> : SNMP ON Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 440 SNMP PUT operations. Notes: The string may not contain more than 128 characters. Related Commands: SNMP SNMP GET SNMP OFF SNMP ON Example: Command<6> : SNMP SET private Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 441 TRAPS RETIRED TRAPS PERSISTENT TRAPS COMMUNITY Example: Command<6> : TRAPS TRAPS : on Version : OCCURRED : on RETIRED : PERSISTENT : on Period Addresses: 198.137.240.91 198.137.240.92 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 442 The addresses 0.0.0.0 and 255.255.255.255 are not permissible addresses. Related Commands: TRAPS TRAPS DELETE TRAPS OFF TRAPS ON TRAPS VERSION Example: Command<6> : TRAPS ADD 198.137.240.91 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 443 Related Commands: TRAPS ADD TRAPS DELETE TRAPS ON TRAPS OFF TRAPS VERSION TRAPS OCCURRED TRAPS RETIRED TRAPS PERSISTENT Example: Command<6> : TRAPS COMMUNITY public Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 444 [address] must be a valid host currently on the list. Related Commands: TRAPS TRAPS ADD TRAPS OFF TRAPS ON TRAPS VERSION Example: Command<6> : TRAPS DELETE 198.137.240.91 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 445 Notes: If TRAPS are disabled altogether via the TRAPS OFF command, Occurred Alarms TRAPS will not be sent regardless of the setting of the Occurred Alarms TRAPS. Related Commands: TRAPS TRAPS ON TRAPS OFF Example: Command<6> : TRAPS OCCURRED OFF Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 446 Comments: This prevents the system from generating TRAPS. If traps are disabled, no trap will be sent under any circumstances. Notes: none Related Commands: TRAPS TRAPS ADD TRAPS DELETE TRAPS ON TRAPS VERSION Example: Command<6> : TRAPS OFF Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 447 Comments: This enables the system to generate a TRAP when required. If traps are enabled, all traps are sent to the configured hosts. Notes: none Related Commands: TRAPS TRAPS ADD TRAPS DELETE TRAPS OFF TRAPS VERSION Example: Command<6> : TRAPS ON Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 448 The system default Persistent Alarm period is 20 minutes. Related Commands: TRAPS TRAPS ON TRAPS OFF Example: Command<6> : TRAPS PERSISTENT OFF ___________________________________________________________________________________ Command<6> : TRAPS PERSISTENT 20 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 449 Notes: If TRAPS are disabled altogether via the TRAPS OFF command, Retired Alarms TRAPS will not be sent regardless of the setting of the Retired Alarms TRAPS. Related Commands: TRAPS TRAPS ON TRAPS OFF Example: Command<6> : TRAPS RETIRED OFF Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 450 Notes: The system supports both Version 1 and Version 2c traps. Related Commands: TRAPS TRAPS ADD TRAPS DELETE TRAPS ON TRAPS OFF Example: Command<6> : TRAPS VERSION V1 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 451 TL1 COMMANDS, AUTONOMOUS MESSAGES, AND ERROR CODES SUPPORTED Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 452 Refer to the current issue of the following Bellcore publications for further information on the NMA system and TL1 command language. TR-NWT-000831 TR-NWT-000833 TR-NWT-000835 TR-NWT-000199 TA-NWT-000199 TA-NWT-000200 TA-NWT-001360 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 453 TL1 Commands Supported Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 454 This section lists the specific TL1 commands (in alphabetical order) the system supports when the TL1 software option is furnished. A brief description of each is provided. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 455 LMS1000 Response Format Variation: The "e" (date and time of last session established by this user) and "f" (number of unsuccessful session attempts since last session) parameters are currently not supported in LMS1000. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 456 These parameters are not implemented in LMS1000. The only valid value for these parameters are NULL. Invalid values received for this parameter return an error response with the error code INUP. LMS1000 Response Format Variation: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 457 LMS1000 session. The user identifier parameter is the NAME attribute from this user’s LMS1000 user configuration. Invalid values received for this parameter return an error response with the error code IIAC. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 458 A user cannot deactivate oneself. If a user attempts to delete oneself, than an error response is returned with the error code PIUC. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 459 00 to 59 Invalid values for this parameter return an error response with the error code IDNV. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 460 IDNV. If the entered value for this parameter matches an existing privilege identifier for another user, an error response with the error code PIUI is returned. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 461 The calling identifier (<cid>) parameter determines the new calling identifier which replaces the current one. This parameter is the new PRIMARY PHONE attribute for the specified user’s LMS1000 user configuration. It Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 462 PIUC. <keyword-defined block> This parameter has no relevance in LMS1000, and is ignored if included. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 463 LMS1000 user is activated. The NAME attribute for this user is changed to that specified by this value. If there are no inactive LMS1000 users remaining, then an error response is returned with the Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 464 Invalid values received for this parameter return an error response with the error code PIUC. <keyword-defined block> This parameter has no relevance in LMS1000, and is ignored if included. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 465 These parameters are not implemented in LMS1000. The only valid value for these parameters are NULL. Invalid values received for these parameters return an error response with the error code INUP. LMS1000 Response Format Variances: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 466 This parameter is not implemented in LMS1000, and must be the value NULL. Null specifies a default value of the current time. Invalid values received for this parameter return an error response with the error code INUP. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 467 LMS1000. The only valid value for this parameter is NULL. A NULL value causes the parameter to default to 1-HR. Invalid values received for this parameter return an error response with the error code IDNV. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 468 This parameter is not supported by LMS1000. The only valid value for this parameter is ALL. Invalid values received for this parameter return an error response with the error code IDNV. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 469 If <ph> is greater than or equal to zero and less than or equal to 127, the error code is IDNV. If <ph> is less than zero or greater than 127, the error code is IORD. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 470 LMS1000 Response Format Variations: Since a normal response cannot be sent after a cold restart, a normal response is sent immediately prior to executing the cold restart function. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 471 ALL. A NULL value is not permitted for this parameter. Invalid values received for this parameter return an error response with the error code IIAC. LMS1000 Response Format Variation: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 472 IDNV. A NULL value for this parameter is not allowed. If a NULL value is received for this parameter, an error response with the error code IDNV is returned. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 473 INUP is returned. Other invalid values received for this parameter return an error response with the error code IDNV. A NULL value for this parameter defaults to the value of CONTS. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 474 LMS1000 channel or limit configuration. Valid values for this parameter are as follows: service-affecting condition nonservice-affecting condition NULL request retrieval of alarm conditions for both of the above codes Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 475 Of-Day - Minute-Of-Hour - Second-Of-Minute). HOD ranges from 0 to 23. MOH and SOM range from 0 to 59. A NULL value means this parameter and the <ocrdat> parameter are not applicable. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 476 LMS1000 channel or limit configuration with which the alarm condition is associated. If the channel or limit parameter has not been configured, a NULL will be inserted for this parameter. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 477 MISC for this attribute is not supported in LMS1000. The error code for an invalid value for this parameter is INUP. <almmsg> This parameter is not supported in LMS1000. LMS1000 Response Format Variations: <ntfcncde> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 478 Of-Day - Minute-Of-Hour - Second-Of-Minute). HOD ranges from 0 to 23. MOH and SOM range from 0 to 59. A NULL value means this parameter and the <ocrdat> parameter are not applicable. <almmsg> This parameter is not supported in LMS1000. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 479 This parameter is an attribute of the LMS1000 channel or limit configuration. Invalid values for this parameter return an error response with the error code IDNV. <locn> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 480 <locn>, <dirn>, <tmper> These parameters do not apply to LMS1000. A NULL value is inserted for them. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 481 Values are derived from the NOTIFICATION CODE attribute of the LMS1000 channel or limit configuration with which the alarm condition is associated. <almtype> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 482 CONDITION TYPE attribute of the LMS1000 channel or limit configuration with which the alarm condition is associated. <almmsg> This parameter is not implemented in LMS1000. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 483 INUP. LMS1000 Response Format Variations: <aidtype> Valid values for an access identifier type response parameter are: EQPT equipment common Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 484 If the condition or state is normal, it defaults to NULL. The format for this parameter is VAL-UN, where valid values for VAL (value) and UN (unit) are: Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 485 LMS1000 channel or limit configuration with which the alarm condition is associated. If the channel or limit parameter has not been configured, a NULL will be inserted for this parameter. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 486 LMS1000 does not support the value of MNTRY for this parameter. <contstate> This is the state of the LMS1000 relay channel. Valid values for the <contstate> parameter are: OPER Operated Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 487 Released The value of NA for this parameter is not supported by LMS1000. The value of this parameter also cannot be NULL. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 488 The access identifier (<aid>) parameter does not apply. The only valid value for this parameter is NULL. Invalid values received for this parameter return an error response with the error code IIAC. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 489 Invalid values for this parameter return an error response with the error code IDNV. LMS1000 Response Format Variations: <lognm> This is the name of the log. Valid values are the same as for the input format. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 490 This parameter does not apply to LMS1000. The only valid value for this parameter is NULL. Invalid values received for this parameter return an error response with the error code IDNV. <tmper> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 491 Valid values for this parameter are: COMPLData accumulated over entire time period A value of NULL for this parameter defaults to COMPL. <locn>, <dirn> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 492 This is the beginning of the time of day of the Performance Monitoring (PM) period. The format for this parameter is HOD-MOH (Hour-Of-Day - Minute-Of-Hour). HOD ranges from 0 to 23. MOH and SOM range from 0 to 59. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 493 IDNV. LMS1000 Response Format Variations: If no threshold can be found which matches the input parameters, an error response with the error code IDNV is returned. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 494 (e.g., for the channel with which the threshold is associated). <tmper> This parameter does not apply in LMS1000. A NULL value is inserted for this parameter. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 495 ACCESS LEVEL attribute from the specified user’s LMS1000 user configuration. <keyword-defined block> This parameter has no relevance in LMS1000 and is not be returned. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 496 This parameter does not apply to LMS1000. The only valid value for this parameter is NULL. Invalid values for this parameter return an error response with the error code IDNV. <dirn> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 497 This parameter does not apply to LMS1000. The only valid value for this parameter is NULL. Invalid values for this parameter return an error response with the error code INUP. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 498 Parameter grouping cannot be used with this parameter. Invalid values for this parameter return an error response with the error code INUP. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 499 Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 500 - character. Invalid values for this parameter return an error response with the error code IDNV. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 501 (e.g., for the channel with which the threshold is associated). This parameter is required in the input. <locn> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 502 This parameter does not apply to LMS1000. The only valid value for this parameter is NULL. Invalid values received for this parameter return an error response with the error code IDNV. LMS1000 Response Format Variations: None Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 503 TL1 Autonomous Messages Supported Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 504 This section lists the specific autonomous messages (in alphabetical order) LMS1000 supports when the TL1 software option is furnished. A brief description of each is provided. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 505 Related Commands: None Related Messages: None LMS1000 Equivalent: "User Timeout" message LMS1000 Message Format Variations: <uid> This refers to the user whose session is terminated due to timeout. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 506 Values are derived from the SERVICE EFFECT CODE attribute of the LMS1000 channel or limit configuration with which the alarm condition is associated. Parameter grouping cannot be used with this parameter. <ocrdat> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 507 NULL will be inserted for this parameter. <aiddet>, <obsdbhvr>, <exptdbhvr>, <dgntype>, <tblistl> These parameters do not apply or are not implemented in LMS1000. A NULL value is inserted for them. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 508 A NULL value for this parameter defaults to the time in the message header. Parameter grouping cannot be used with this parameter. <almmsg> This parameter is not implemented in LMS1000. A NULL value is inserted for this parameter. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 509 This is the service effect parameter associated with a single alarm condition given in this block. Valid values are as follows: Service-affecting condition immediate action required. Nonservice-affecting condition, action required. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 510 VAL-UN, where valid values for VAL (value) and UN (unit) are: VAL (value) UN (unit) DAY (day) 1 to 24 HR (hour) 1 to 1440 MIN (minute) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 511 MOY-DOM (Month-Of-Year - Day-Of-Month). MOY ranges from 1 to 12, and DOM ranges from 1 to 31. A null value for this parameter defaults to the date in the message header. <ocrtm> Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 512 NULL will be inserted for this parameter. <aiddet>, <obsdbhvr>, <exptdbhvr>, <dgntype>, <tblistl> These parameters do not apply or are not implemented in LMS1000. A NULL value is inserted for them. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 513 List of Error Codes for TL1 Commands Supported Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 514 SAOP - Status, Already OPerated SCNF - Status, Command Not Found SDNR - Status, Data Not Ready SPNF - Status, Process Not Found SROF - Status, Requested Operation Failed Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 515 Dispose of used batteries according to the manufacturer's instructions. Vertiv Co. recommends that the memory backup battery be replaced once a year. The CPU circuit card employs a 3 volt 170 mAH lithium battery (P/N 241163100) which has a shelf life of ten years.
  • Page 516 (arrow on fastener points towards outside of cabinet). 582140000/582140001/582126100 Power System: Close the bay's front door. Re-apply DC input power to the LMS1000 CPU circuit card. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 517 Figure 4: Replacing the CPU Memory Backup Battery (Main Cabinet or Primary Bay Only) (cont’d on next page) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 518 Figure 4: Replacing the CPU Memory Backup Battery (Main Cabinet or Primary Bay Only) (cont’d from previous page) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 519 • Connect the phone line. • Configure modem parameters. Upgrading the Firmware Contact a Vertiv Co. service facility. Contact information is provided in a Service Information Sheet (Section 4154). Section 4154 can be accessed via the CD (Electronic Documentation Package) furnished with your system.
  • Page 520 The system contains a self-diagnostic feature. If the system automatically enters the diagnostic mode (distinguished by RED flashing LEDs or no response to access attempts), contact a Vertiv Co. service facility. Contact information is provided in a Service Information Document (Section 4154). The Service Information Document can be accessed via the CD (Electronic Documentation Package) furnished with your system.
  • Page 521 Hardware Fail channels alarm. Contact a Vertiv Co. service facility if the following "Actions" do not eliminate the error condition. Contact information is provided in a Service Information Sheet (Section 4154). Section 4154 can be accessed via the CD (Electronic Documentation Package) furnished with your system.
  • Page 522 Verify the error clears within 15 seconds. Temperature Description: Temperature probe sensor has failed. Probe Failure Action: Replace the temperature probe specified by the ALARMS command. (B0096) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 523 Verify (and change if necessary) the channel configuration. scale factor of this channel. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 524 Replace the analog input circuit card with a known working Analog Input circuit card. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 525 Download the configuration from the LMS1000 to a PC by following one of the procedures detailed next. Downloading the Configuration from the LMS1000 to a PC using XMODEM Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 526 Power System, note that if a modem is installed, it also contains a bracket with a retaining screw. Remove the modem cable, if present. Remove the modem circuit card, if present. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 527 At the PC, initiate a file transfer using XMODEM CRC protocol. When the transfer is complete, the following is displayed. 84 blocks received OK. Upload Complete. The number of blocks received may vary. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 528 582140000/582140001/582126100 Power System: Open the bay's front door. Connect an approved grounding strap to your wrist. Attach the other end to a suitable ground. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 529 Log onto the system as a level 6 user. Enter the command NODE REPLACE. Enter the correct information for the node whose CPU is being replaced and the new node CPU being installed. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 530 Figure 5: CPU Circuit Card Replacement (cont’d on next page) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 531 Figure 5: CPU Circuit Card Replacement (cont’d from previous page) Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 532 Section 5879 is also provided on the CD (Electronic Documentation Package) furnished with your system. • Install the circuit card. • Wire to the circuit card. • Configure the associated channels of the circuit card. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 533 Note that the configuration for the channels on the source node may need re- configuring after executing the NODE INITIO command. Refer to the "NODE INITIO" command in the Commands section. Vertiv™ | NetSure™ LMS Data Processing Unit User Manual (Section 5847) | Rev. ZA...
  • Page 534 Vertiv.com | Vertiv Headquarters, 1050 Dearborn Drive, Columbus, OH, 43085, USA © 2021 Vertiv Group Corp. All rights reserved. Vertiv™ and the Vertiv logo are trademarks or registered trademarks of Vertiv Group Corp. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness here, Vertiv Group Corp.

This manual is also suitable for:

586505000586505500

Table of Contents
