GD310-UL series VFD

4.3 Standard wiring

4.3.1 Connection diagram of main circuit

Connection diagram of main circuit for the VFDs of AC 3PH 380V–480V
3-PH power supply
3-PH power supply
50/60Hz
Figure 4-8 Connection diagram of main circuit for the VFDs of
Note:
 The fuse, DC reactor, braking unit, braking resistor, input reactor, input filter, output reactor,
output filter are optional parts. Please refer to Peripheral options and parts for detailed
information.
 P1 and (+) are short circuited in factory for the VFDs of 220V (≥18.5kW), 460V (G-type≥37kW,
P-type≥45kW), if need to connect with the DC rector, please remove the jumper between P1 and
(+).
 Remove the yellow warning labels of PB, (+) and (-) on the terminals before connecting the
braking resistor; otherwise, poor connection may occur.
3-PH power supply
Figure 4-9 Connection diagram of main circuit for the VFDs of 575V
Input
reactor
Input
50/60Hz
filter
Fuse
Figure 4-7 Connection diagram of main circuit for the VFD of
220V ≤15kW; 460V G-type≤30kW, P-type≤37kW
Input
reactor
Input
filter
Fuse
220V 18.5–55kW; 460V G-type≥37kW, P-type≥45kW
Input
reactor
Input
50/60Hz
filter
Fuse
Braking resistor
VFD
Braking unit
DC reactor
VFD
Braking unit
DC reactor
-22-
Installation guidelines
Output
reactor
Output
filter
Braking resistor
Output
reactor
Output
filter
Braking resistor
Output
reactor
Output
filter
