GD310-UL series VFD
Function
instruction
Operation
frequency
Setting frequency
Bus voltage
Output voltage
Output current
Rotation speed
Output power
Output torque
Close loop setting
Close loop
feedback
Input IO state
Output IO state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of
high-speed pulse 1
Read input of
high-speed pulse 2
Read the current
stage of multi-step
speed
External length
External counting
Torque setting
Identifying code of
the VFD
Fault code
R/W characteristics means the function is with read and write characteristics. For example,
"communication control command" is writing chrematistics and control the VFD with writing command
(06H). R characteristic can only read other than write and W characteristic can only write other than
read.
Note: when operate on the VFD with the table above, it is necessary to enable some parameters. For
example, the operation of running and stopping, it is necessary to set P00.01 to communication
Address
definition
3000H 0–Fmax (unit: 0.01Hz)
3001H 0–Fmax (unit: 0.01Hz)
3002H 0.0–2000.0V (unit: 0.1V)
3003H 0–1200V (unit: 1V)
3004H 0.0–3000.0A (unit: 0.1A)
3005H 0–65535 (unit: 1RPM)
3006H -300.0–300.0% (unit: 0.1%)
3007H -250.0–250.0% (unit: 0.1%)
3008H -100.0–100.0% (unit: 0.1%)
3009H -100.0–100.0% (unit: 0.1%)
300AH 000–1FF
300BH 000–1FF
300CH 0.00–10.00V (unit: 0.01V)
300DH 0.00–10.00V (unit: 0.01V)
300EH 0.00–10.00V (unit: 0.01V)
300FH /
3010H 0.00–50.00kHz (unit: 0.01Hz)
3011H /
3012H 0–15
3013H 0–65535
3014H 0–65535
3015H -300.0–300.0% (unit: 0.1%)
3016H /
5000H /
Data meaning instruction
-202-
Communication protocol
R/W
attribute
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
