Canopen Optional Cards - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Fault display LEDs
LED
Name
No.
2 Online
4 Offline/Fault

CANopen optional cards

A.3
Refer to the operation manual of EC-TX105 CANopen communication cards.
Color
ON-module online and data can be exchanged.
Green
OFF-module is not in "online" state.
ON-module offline and data can't be exchanged.
OFF-module is not in "offline" state.
1. Flicker frequency 1Hz-configuration error: The length of user
parameter data sets is different from that of network configuration
process during module initialization process.
Red 2. Flicker frequency 2Hz-user parameter data error: The length or
content of user parameter data sets is different from that of network
configuration process during module initialization process.
3. Flicker frequency 4Hz-PROFIBUS communication ASIC
initialization error.
4. OFF-Diagnostic closed.
Function
-226-
Expansion card
