GD310-UL series VFD

4.3.6 Input /Output signal connection figure

Please use U-shaped jumper to set NPN mode or PNP mode and the internal or external power
supply. The default setting is NPN internal mode.
If the signal is from NPN transistor, please set the U-shaped jumper between +24V and PW as below
according to the used power supply.
If the signal is from PNP transistor, please set the U-shaped jumper as below according to the used
power supply.
COM
PW
+24V
Figure 4-23 U-shaped jumper
S1
S2
COM
COM
+24V
PW
+24V
Figure 4-24 NPN modes
S1
S2
COM
+24V
Figure 4-25 PNP modes
Torsional moment :35 ibf in
U-shaped jumper
between
PW and COM
+24V
-30-
Installation guidelines
U-shaped jumper
between
COM and CME
S1
S2
COM
COM
+24V
PW
+24V
S1
S2
COM
COM
+24V
PW
+24V
.
