P17 Group Monitoring Function - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Function
Name
code
P16.09 Gateway 1
P16.10 Gateway 2
P16.11 Gateway 3
P16.12 Gateway 4

P17 Group Monitoring function

Function
Name
code
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
Exciting
P17.07
current
P17.08 Motor power
P17.09 Output torque
Evaluated
P17.10 motor
frequency
DC bus
P17.11
voltage
Digital input
P17.12
terminals state
0–255
Set the gateway of Ethernet communication
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
Display current ramp given frequency of the VFD
Range: 0.00Hz–P00.03
Display current output voltage of the VFD
Range: 0–1200V
Display current output current of the VFD
Range: 0.0–3000.0A
Display the rotation speed of the motor.
Range: 0–65535RPM
Display current torque current of the VFD
Range: -3000.0–3000.0A
Display current exciting current of the VFD
Range: -3000.0–3000.0A
Display current power of the motor.
Setting range: -300.0%–300.0% (rated motor current)
Display the current output torque of the VFD.
Range: -250.0–250.0%
Evaluate the motor rotor frequency on close loop
vector
Range: 0.00– P00.03
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
Display current Switch input terminals state of the
VFD
BIT8
HDI
BIT4 BIT3
S5 S4
Description
Description
BIT7 BIT6
S8 S7
BIT2 BIT1
S3 S2
-111-
Function parameter
Default
value
192
168
1
1
Default
value
0.00Hz
0.00Hz
0.00Hz
0V
0.0A
0 RPM
0.0A
0.0A
0.0%
0.0%
0.00Hz
0.0V
BIT5
0
S6
BIT0
S1
