GD310-UL series VFD
Function
code
P06.17 Lower output limit of AO1 -100.0%–P06.19
Corresponding AO1
P06.18
P06.19 Upper output limit of AO1 P06.17–100.0%
The corresponding AO1
P06.20
output of upper limit
P06.21 AO1 output filter time
P06.22 Lower output limit of AO2 -100.0%–P06.24
Corresponding AO2
P06.23
P06.24 Upper output limit of AO2 P06.22–100.0%
The corresponding AO2
P06.25
output of upper limit
P06.26 AO2 output filter time
P06.27 Lower output limit of HDO -100.0%–P06.29
Corresponding HDO
P06.28
P06.29 Upper output limit of HDO P06.27–100.0%
Corresponding HDO
P06.30
output of upper limit
P06.31 HDO output filter time
Name
output of lower limit
output of lower limit
output of lower limit
Description
13: High speed pulse HDI input value
14: MODBUS communication set value 1
15: MODBUS communication set value 2
16: PROFIBUS/CANopen communication
set value 1
17: PROFIBUS/CANopen communication
set value 2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20–21: Reserved
22: Torque current (relative to the rated
current of the motor)
23: Pre-magnetizing current (relative to the
rated current of the motor)
24–30: Reserved
0.00V–10.00V
0.00V–10.00V
0.000s–10.000s
0.00V–10.00V
0.00V–10.00V
0.000s–10.000s
0.00–50.00kHz
0.00–50.00kHz
0.000s–10.000s
-146-
Basic operation instruction
Default
value
0.0%
0.00V
100.0%
10.00V
0.000s
0.0%
0.00V
100.0%
10.00V
0.000s
0.00%
0.0kHz
100.0%
50.00kHz
0.000s
