INVT Goodrive 310-UL Series Operation Manual page 241

GD310-UL series VFD
Wall installation of 460V G-type 37–110kW, P-type 45–110kW VFDs
Wall installation of 460V G-type 132–200kW, P-type 132–220kW VFDs
Model
GD310-0R7G-2-UL
GD310-(1R5G-2R2G)-2-UL
GD310-(004G-5R5G)-2-UL
GD310-7R5G-2-UL
GD310-(011G-015G)-2-UL
GD310-(018G-030G)-2-UL
GD310-(037G-055G)-2-UL
Model
GD310-(1R5G-2R2G)-4-UL
GD310-(004G-5R5G)-4-UL
Wall installation of 220V 18.5–-55kW VFDs
Wall installation of 575V 18.5–110kW VFDs
Wall installation dimension of 220V 0.75–55kW (unit: mm)
W1 W2
126 115
146 131
170 151
230 210
255 237
270 130
325 200
Wall installation dimension of 460V G-type 1.5–200kW
W1 W2
126 115
146 131
H1 H2 D1
193 175 174.5
263 243.5 181
331.5 303.5 216
342 311 216
407 384 245
555 540 325
680 661 365
H1 H2 D1
193 175 174.5
263 243.5 181
-233-
Dimension drawings
Installation hole
Ø5
Ø6
Ø6
Ø6
Ø7
Ø7
Ø9.5
Installation hole
Ø5
Ø6
