GD310-UL series VFD
Environment
Storage
-30–+60° C
temperature
The installation site of the VFD should:
 keep away from the electromagnetic radiation source;
Running  keep away from contaminative air, such as corrosive gas, oil mist and
environment flammable gas;
condition  ensure foreign objects, such as metal power, dust, oil, water cannot enter into
the VFD (do not install the VFD on the flammable materials such as wood);
 keep away from direct sunlight, oil mist, steam and vibration environment.
<1000m
When the installation site altitude exceeds 1000m, derate 1% for every increase
Altitude
of 100m; when the installation site altitude exceeds 3000m, consult the local INVT
dealer or office.
≤ 5.88m/s
Vibration
Installation The VFD should be installed on an upright position to ensure sufficient cooling
direction effect.
Note:
 Goodrive310-UL series VFDs should be installed in a clean and ventilated environment
according to enclosure classification.
 Cooling air must be clean, free from corrosive materials and electrically conductive dust.

4.2.2 Installation direction

The VFD may be installed in a cabinet.
The VFD must be installed in an upright position. Check the installation site according to the
requirements below. Refer to chapter Dimension drawings in the appendix for frame details.
OK
a
Vertical installation
2
(0.6g)
NG
b
Horizontal installation
Figure 4-1 Installation direction of the VFD
Conditions
-17-
Installation guidelines
NG
c
Transverse installation
