INVT Goodrive 310-UL Series Operation Manual page 51

GD310-UL series VFD
Function
Name
code
Keypad set
P00.10
frequency
ACC time 1
P00.11
P00.12 DEC time 1
Running
P00.13
direction
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note: The combination manner can be shifted by P5
(terminal function)
When A and B frequency commands are selected as
"keypad setting", the value of the function code is the
original setting one of the frequency data of the VFD.
Setting range: 0.00 Hz–P00.03 (the max frequency)
ACC time means the time needed if the VFD speeds
up from 0Hz to the max One (P00.03).
DEC time means the time needed if the VFD speeds
down from the max Output frequency to 0Hz
(P00.03).
Goodrive310-UL series VFDs define four groups of
ACC/DEC time which can be selected by P05. The
factory default ACC/DEC time of the VFD is the first
group.
Setting range of P00.11 and P00.12: 0.0–3600.0s
0: Runs at the default direction, the VFD runs in the
forward direction. FWD/REV indicator is off.
1: Runs at the reverse direction, the VFD runs in the
reverse direction. FWD/REV indicator is on.
Modify the function code to shift the rotation direction
of the motor. This effect equals to the shifting the
rotation direction by adjusting either two of the motor
lines (U, V and W). The motor rotation direction can
be changed by QUICK/JOG on the keypad. Refer to
parameter P07.02.
Note: When the function parameter comes back to
the default value, the motor's running direction will
come back to the factory default state, too. In some
cases it should be used with caution after
commissioning if the change of rotation direction is
disabled.
Description
-43-
Function parameter
Default
Modify
value
○
60.00Hz
Depend
○
on model
Depend
○
on model
○
0
