INVT Goodrive 310-UL Series Operation Manual page 21

GD310-UL series VFD
Model
GD310-7R5P-4-UL
GD310-011P-4-UL
GD310-015P-4-UL
GD310-018P-4-UL
GD310-022P-4-UL
GD310-030P-4-UL
GD310-037P-4-UL
GD310-045P-4-UL
GD310-055P-4-UL
GD310-075P-4-UL
GD310-090P-4-UL
GD310-110P-4-UL
GD310-132P-4-UL
GD310-160P-4-UL
GD310-185P-4-UL
GD310-200P-4-UL
GD310-220P-4-UL
GD310-250P-4-UL
GD310-280P-4-UL
GD310-315P-4-UL
GD310-350P-4-UL
GD310-400P-4-UL
GD310-500P-4-UL
Note:
 The input current of VFDs (G-type: 1.5–200kW, P-type: 5.5–220kW) is detected when the input
voltage is 460V and there is no DC reactors and input/output reactors.
 The input current of VFDs (G-type: 220–500kW, P-type: 250–500kW) is detected when the
input voltage is 460V and there are input reactors.
 The rated output current is defined when the output voltage is 460V.
 The output current cannot exceed the rated output current and the output power cannot exceed
the rated output power in the voltage range.
Rated output power
(kW)
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
Rated input current
(A)
25
32
40
47
56
70
80
94
128
160
190
225
265
310
345
385
430
485
545
610
625
715
890
-13-
Product Overview
Rated output current
(A)
18.5
25
32
38
45
60
75
92
115
150
180
215
260
305
340
380
425
480
530
600
650
720
860
