Pulse Counter - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Function
code
P00.03 Max output frequency P00.03–400.00Hz
P00.06 A frequency command
P00.11 ACC time 1
P00.12 DEC time 1
P05.01– Digital input function
P05.09 selection
P08.15 Traverse range
Sudden jumping
P08.16
frequency range
P08.17 Traverse boost time
P08.18 Traverse declining time 0.1–3600.0s

7.17 Pulse counter

Goodrive310-UL series VFDs support pulse counter which can input counting pulse through HDI
terminal. When the actual length is longer than or equal to the set length, the digital output terminal
can output length arrival pulse signal and the corresponding length will clear automatically.
Name
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Simple PLC program setting
6: Multi-step speed running setting
7: PID control setting
8: MODBUS communication setting
9: PROFIBUS/CANopen communication setting
10: Ethernet communication setting (reserved)
11: Reserved
0.0–3600.0s
0.0–3600.0s
26: Traverse Pause (stop at present frequency)
27: Traverse reset (return to center frequency)
0.0–100.0% (relative to the set frequency)
0.0–50.0% (relative to the traverse range)
0.1–3600.0s
Description
