INVT Goodrive 310-UL Series Operation Manual page 86

GD310-UL series VFD
Function
Name
code
High bit of
P07.15 power
consumption
Low bit of
P07.16 power
consumption
P07.17 Reserved
Rated power
P07.18
of the VFD
Rated voltage
P07.19
of the VFD
Rated current
P07.20
of the VFD
Factory bar
P07.21
code 1
Factory bar
P07.22
code 2
Factory bar
P07.23
code 3
Factory bar
P07.24
code 4
Factory bar
P07.25
code 5
Factory bar
P07.26
code 6
Type of
P07.27
present fault
Type of the
P07.28
last fault
Type of the
P07.29 last but one
fault
Type of the
P07.30 last but two
fault
Type of the
P07.31 last but three
fault
Display the power used by the VFD.
The power consumption
=P07.15*1000+P07.16
Setting range of P07.15: 0–65535 kWh (*1000)
Setting range of P07.16: 0.0–999.9 kWh
Reserved
0.4–3000.0kW
50–1200V
0.1–6000.0A
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0: No fault
1: IGBT U phase protection (OUt1)
2: IGBT V phase protection (OUt2)
3: IGBT W phase protection (OUt3)
4: Overcurrent during acceleration (OC1)
5: Overcurrent during deceleration (OC2)
6: Overcurrent during constant speed running (OC3)
7: Overvoltage during acceleration (OV1)
8: Overvoltage during deceleration (OV2)
9: Overvoltage during constant speed running (OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: VFD overload (OL2)
13: Phase loss on input side (SPI)
Description
of
-78-
Function parameter
Default
value
the VFD
Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
