GD310-UL series VFD
Note:
 The input current of VFDs 0.75–55kW is detected when the input voltage is 220V and there are
no DC reactors and input/output reactors.
 The rated output current is defined when the output voltage is 220V.
 The output current cannot exceed the rated output current and the output power cannot exceed
the rated output power in the voltage range.

3.6.2 The VFDs of AC 3PH 380V-480V

Model
GD310-1R5G-4-UL
GD310-2R2G-4-UL
GD310-004G-4-UL
GD310-5R5G-4-UL
GD310-7R5G-4-UL
GD310-011G-4-UL
GD310-015G-4-UL
GD310-018G-4-UL
GD310-022G-4-UL
GD310-030G-4-UL
GD310-037G-4-UL
GD310-045G-4-UL
GD310-055G-4-UL
GD310-075G-4-UL
GD310-090G-4-UL
GD310-110G-4-UL
GD310-132G-4-UL
GD310-160G-4-UL
GD310-185G-4-UL
GD310-200G-4-UL
GD310-220G-4-UL
GD310-250G-4-UL
GD310-280G-4-UL
GD310-315G-4-UL
GD310-350G-4-UL
GD310-400G-4-UL
GD310-500G-4-UL
GD310-5R5P-4-UL
Rated output power
(kW)
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
350
400
500
5.5
Rated input current
(A)
5.0
5.8
13.5
19.5
25
32
40
47
56
70
80
94
128
160
190
225
265
310
345
385
430
485
545
610
625
715
890
19.5
-12-
Product Overview
Rated output current
(A)
3.7
5.0
9.5
14
18.5
25
32
38
45
60
75
92
115
150
180
215
260
305
340
380
425
480
530
600
650
720
860
14
