GD310-UL series VFD
Function
Name
code
Current limit
P11.05 action
selection
Automatic
P11.06
current limit
Frequency-de
creasing ratio
P11.07
during current
limit
Overload
pre-alarm of
P11.08
motor/
VFD
The actual increasing ratio of motor speed is lower
than the ratio of output frequency because of the big
load during ACC running. It is necessary to take
measures to avoid overcurrent fault and VFD
tripping.
Ones: current limit:
0: Invalid
1: Valid
Tens: overload alarm of hardware current limit (for
factory commissioning)
0: Valid
1: Invalid
During the running of the VFD, it will detect the
output current and compare it with the limit level
defined in P11.06. If it exceeds the level, the VFD will
run at stable frequency in ACC running, or the VFD
will derate to run during the constant running. If it
exceeds the level continuously, the output frequency
will keep on decreasing to the lower limit. If the
output current is detected to be lower than the limit
level, the VFD will accelerate to run.
Output current
Limiting
point
Output frequency
Set
frequency
Setting range of P11.06: 50.0–200.0%
(corresponding to the rated output current of the
VFD)
Setting range of P11.07: 0.00–50.00Hz/s
The output current of the VFD or the motor is above
P11.09 and the lasting time is beyond P11.10,
overload pre-alarm will be output.
Description
Constant
ACC
speed
-97-
Function parameter
Default
Modify
value
◎
01
◎
160.0%
T
10.00Hz/
◎
s
T
○
0x000
