INVT Goodrive 310-UL Series Operation Manual page 120

GD310-UL series VFD
Function
Name
code
Digital output
P17.13
terminals state
Digital
P17.14
adjustment
Torque
P17.15
reference
P17.16 Linear speed
Length
P17.17
Counting
P17.18
value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
AI3 input
P17.21
voltage
HDI input
P17.22
frequency
P17.23 PID reference
P17.24 PID feedback
Power factor
P17.25
of the motor
Current
P17.26
running time
Simple PLC
and the
current step of
P17.27
the multi-step
speed
Range: 0000–01FF
Display current Switch output terminals state of the
VFD
BIT3 BIT2
RO2 RO1
Range: 0000–000F
Display the adjustment through the keypad of the
VFD.
Range : 0.00Hz–P00.03
Display the torque given, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0% (rated motor current)
Display the current linear speed of the VFD.
Range: 0–65535
Display the current length of the VFD.
Range: 0–65535
Display the current counting number of the VFD.
Range: 0–65535
Display analog AI1 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: -10.00–10.00V
Display HDI input frequency
Range: 0.000–50.000kHz
Display PID given value
Range: -100.0–100.0%
Display PID response value
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display the current running time of the VFD.
Range: 0–65535m
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
Description
BIT1
HDO
-112-
Function parameter
Default
value
BIT0 0
Y
0.00Hz
0.0%
0
0
0
0.00V
0.00V
0.00V
0.000
kHz
0.0%
0.0%
0.0
0m
0
Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
