INVT Goodrive 310-UL Series Operation Manual page 69

GD310-UL series VFD
Function
Name
code
at low
frequency of
motor 1
Vibration
control factor
at high
P04.11
frequency of
motor 1
Vibration
control
P04.12
threshold of
motor 1
Motor 2 V/F
P04.13
curve setting
Torque boost
P04.14
of motor 2
Torque boost
close of motor
P04.15
2
V/F frequency
P04.16
1 of motor 2
V/F voltage 1
P04.17
of motor 2
V/F frequency
P04.18
2 of motor 2
V/F voltage 2
P04.19
of motor 2
V/F frequency
P04.20
3 of motor 2
V/F voltage 3
P04.21
of motor 2
V/F slip
P04.22 compensation
gain of motor 2
Vibration
control factor
P04.23 at low
frequency of
motor 2
occur to the motor at some frequency, especially the
motor with big power. The motor cannot run stably or
overcurrent may occur. These phenomena can be
canceled by adjusting this parameter.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (the max
frequency)
This group of parameters defines the V/F setting
means of Goodrive310-UL motor 2 to meet various
requirements of different loads. See P04.00–P04.12
for the detailed function code instruction.
Note: P04 group includes two sets of V/F parameters
of the motor which cannot display simultaneously.
Only the selected V/F parameter can be shown. The
motor selection can be defined by terminals function
"the shift between motor 1 and motor 2"
In SVPWM control mode, current fluctuation may
occur to the motor on some frequency, especially the
motor with big power. The motor cannot run stably or
overcurrent may occur. These phenomena can be
Description
-61-
Function parameter
Default
Modify
value
○
10
○
30.00Hz
◎
0
○
0.0%
○
20.0%
○
0.00Hz
○
00.0%
○
00.00Hz
○
00.0%
○
00.00Hz
○
00.0%
○
100.0%
○
10
