GD310-UL series VFD

3.6.3 The VFDs of AC 3PH 520V-600V

Model
GD310-018G-6-UL
GD310-022G-6-UL
GD310-030G-6-UL
GD310-037G-6-UL
GD310-045G-6-UL
GD310-055G-6-UL
GD310-075G-6-UL
GD310-090G-6-UL
GD310-110G-6-UL
Note:
 The input current of VFDs 18.5–110kW is detected when the input voltage is 575V and there is
no DC reactors and input/output reactors.
 The rated output current is defined when the output voltage is 575V.
 The output current cannot exceed the rated output current and the output power cannot exceed
the rated output power in the voltage range.

3.7 Structure diagram

Below is the layout figure of the VFD (take the VFD of 460V G-type 30kW as the example).
Rated output power
(kW)
18.5
22
30
37
45
55
75
90
110
Figure 3-6 Product structure
Rated input current
(A)
35
40
47
52
65
85
95
118
145
-14-
Product Overview
Rated output current
(A)
27
35
45
52
62
86
98
120
150
