GD310-UL series VFD
Function
Name
code
P07.49 Running frequency at the last but one fault
P07.50 Output voltage at the last but one faults
P07.51 Output current at the last but one faults
P07.52 Output current at the last but one fault
P07.53 Bus voltage at the last but one fault
P07.54 The max temperature at the last but one fault
P07.55 Input terminals state at the last but one fault
P07.56 Output terminals state at the last but one fault

P08 Group Enhanced function

Function
Name
code
P08.00 ACC time 2
P08.01 DEC time 2
P08.02 ACC time 3
P08.03 DEC time 3
P08.04 ACC time 4
P08.05 DEC time 4
Jogging
P08.06
frequency
Jogging ACC
P08.07
time
Jogging DEC
P08.08
time
Jumping
P08.09
frequency 1
Jumping
P08.10 frequency
range 1
Jumping
P08.11
frequency 2
See P00.11 and P00.12 for detailed definition.
Goodrive310-UL series define four groups of
ACC/DEC time which can be selected by P5 group.
The first group of ACC/DEC time is the factory
default one.
Setting range: 0.0–3600.0s
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz –P00.03 (the max frequency)
The jogging ACC time means the time needed if the
VFD runs from 0Hz to the max Frequency.
The jogging DEC time means the time needed if the
VFD goes from the max frequency (P0.03) to 0Hz.
Setting range: 0.0–3600.0s
When the set frequency is in the range of jumping
frequency, the VFD will run at the edge of the
jumping frequency.
The VFD can avoid the mechanical resonance point
by setting the jumping frequency. The VFD can set
three jumping frequency. But this function will be
invalid if all jumping points are 0.
Description
Description
-80-
Function parameter
Default
Modify
value
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0.0V
●
0.0° C
●
0
●
0
Default
Modify
value
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
○
5.00Hz
Depend
○
on model
Depend
○
on model
○
0.00Hz
○
0.00Hz
○
0.00Hz
