INVT Goodrive 310-UL Series Operation Manual page 33

GD310-UL series VFD
Figure 4-16 Terminals of main circuit for the VFDs of 220V 37–55kW
460V G-type 75–110kW, P-type 75–110kW and 575V 45–110kW
POWER
T
Figure 4-17 erminals of main circuit for the VFDs of
460V G-type 132–200kW, P-type 132–220kW
T
Figure 4-18 erminals of main circuit for the VFDs of
460V G-type 220–315kW, P-type 250–350kW
-25-
Installation guidelines
