GD310-UL series VFD
Flange installation of 460V G-type 37–110kW, P-type 45–110kW and 575V VFDs
Flange installation of 460V G-type 132–200kW, P-type 132–200kW VFDs
Flange installation dimension of 220V 0.75–55kW VFDs (unit: mm)
Model
GD310-0R7G-2-UL
GD310-(1R5G-2R2G)-2-UL 170 131 150 9.5 292 276 260 10
GD310-(004G-5R5G)-2-UL 191 151 174 11.5 370 351 324 15 216.2 113
GD310-7R5G-2-UL
GD310-(011G-015G)-2-UL
GD310-(018G-030G)-2-UL
GD310-(037G-055G)-2-UL
Flange installation of 220V 18.5–55kW VFDs
W1 W2 W3 W4 H1 H2 H3 H4
150 115 130 7.5 234 220 190 16.5 174.5 65.5
250 210 234 12 375 356 334 10
275 237 259 11 445 426 404 10
270 130 261 65.5 555 540 516 17
325 200 317 58.5 680 661 626 23
-235-
Dimension drawings
Installation
D1 D2
hole
Ø5
181 79.5 Ø6
Ø6
216 108 Ø6
245 119 Ø7
325 167 Ø7
363 182 Ø9.5
