INVT Goodrive 310-UL Series Operation Manual page 162

GD310-UL series VFD
Set
Function
value
4 Jogging
5 VFD fault
6 FDT1
7 FDT2
8 Frequency arrival Please refer to P08.36 for detailed information.
Zero-speed
9
running
Upper-limit
10
frequency arrival
Upper-limit
11
frequency arrival
12 Ready
13 Pre-exciting
Overload
14
pre-alarm
Underload
15
pre-alarm
Simple PLC stage
16
completion
Simple PLC cycle
17
completion
18 Set counting arrival
Fixed counting
19
arrival
20 External fault valid Output ON signal if external fault occurs.
21 Length arrival
Running time
22
arrival
MODBUS
communication
23
virtual terminal
output
Output ON signal when the VFD is jogging and there is frequency
output.
Output ON signal when the VFD is in fault
Please refer to P08.32 and P08.33 for detailed information.
Please refer to P08.34 and P08.35 for detailed information.
Output ON signal when the output frequency and given frequency of
the VFD is 0 at the same time.
Output ON signal when the running frequency of the VFD is the upper
limit frequency.
Output ON signal when the running frequency of the VFD is the lower
limit frequency.
When the main circuit and the control circuit is established and the
protection function of the VFD is not active. The VFD is in the running
state and it will output ON signal.
Output ON signal when the VFD is in the pre-exciting state.
Output ON signal if the VFD is beyond the pre-alarm point. Refer to
P11.08–P11.10 for the detailed instruction.
Output ON signal if the VFD is beyond the pre-alarm point. Refer to
P11.11–P11.12 for the detailed instruction.
Output signal if the simple PLC stage is completed.
Output signal if the simple PLC cycle is completed.
Output ON signal if the detected counting exceeds the set value of
P08.25.
Output ON signal if the detected counting exceeds the set value of
P08.26.
Output ON signal if the actual detected length exceeds the se length
by P08.19.
Output ON signal if the accumulative running time of the VFD exceeds
the setting time by P08.27.
Output corresponding signal according to the setting value of
MODBUS. Output ON signal if the setting value is 1 and output OFF
signal if the setting value is 0.
-154-
Basic operation instruction
Instructions
