INVT Goodrive 310-UL Series Operation Manual page 181

GD310-UL series VFD
Fault
Fault type
code
[3] IGBT W
phase
OUt3
protection
[4] Overcurrent
OC1 during
acceleration
[5] Overcurrent
OC2 during
deceleration
[6] Overcurrent
OC3 during constant
speed running
[7] Overvoltage
OV1 during
acceleration
[8] Overvoltage
OV2 during
deceleration
[9] Overvoltage
OV3 during constant
speed running
[10] Bus
UV
undervoltage
[11] Motor
OL1
overload
Cause
driving wires is not good

The grounding is not good

The acceleration or
deceleration is too fast

The voltage of the grid is too
low

The power of the VFD is too
low

The load transients or is
abnormal

The grounding is short
circuited or the output is
phase loss

There is strong external
interference

The overvoltage stall
protection is not open

The input voltage is
abnormal

There is large energy
feedback

No braking components

Braking energy is not open

The voltage of the power
supply is too low

The overvoltage stall
protection is not open

The voltage of the power
supply is too low

The motor setting rated
current is incorrect

The motor stall or load
transients is too strong
-173-
Solution
equipment

Increase the acc. time

Check the input power

Select the VFD with a larger
power

Check if the load is short circuited
(the grounding short circuited or
the wire short circuited) or the
rotation is not smooth

Check the output configuration.

Check if there is strong
interference

Check the setting of related
function codes

Check the input power

Check if the DEC time of the load
is too short or the VFD starts
during the rotation of the motor or
it needs to increase the energy
consumption components

Install the braking components

Check the setting of related
function codes

Check the input power of the
supply line

Check the setting of related
function codes

Check the power of the supply
line

Reset the rated current of the
motor

Check the load and adjust the
torque lift
Fault tracking
