INVT Goodrive 310-UL Series Operation Manual page 140

GD310-UL series VFD
Related parameters list:
Function
code
P00.01 Run command channel
P00.15 Motor parameter autotuning
P02.00
P02.01 Rated power of AM 1
P02.02 Rated frequency of AM 1
P02.03 Rated speed of AM 1
P02.04 Rated voltage of AM 1
P02.05 Rated current of AM 1
P02.06 Stator resistor of AM 1
P02.07 Rotor resistor of AM 1
P02.08 Leakage inductance of AM 1 0.1–6553.5mH
P02.09 Mutual inductance of AM 1
P02.10 Non-load current of AM1
P02.15 Rated power of SM 1
P02.16 Rated frequency of SM 1
Number of poles pairs for SM
P02.17
P02.18 Rated voltage of SM 1
P02.19 Rated current of SM 1
P02.20 Stator resistor of SM 1
Direct axis inductance of SM
P02.21
Quadrature axis inductance
P02.22
P02.23 Back EMF constant of SM 1 0–10000
Name
Motor type 1
1
1
of SM 1
Description
0: Keypad running command
1: Terminal running command
channel ("LOCAL/REMOT"
flickering)
2: Communication running command
channel ("LOCAL/REMOT" on);
0: No operation
1: Rotating autotuning
2: Static autotuning 1 (autotune
totally)
3: Static autotuning 2 (autotune part
parameters)
0: Asynchronous motor
1: Synchronous motor
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–36000rpm
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5A
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–50
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
0.01–655.35mH
-132-
Basic operation instruction
Default value
0
0
0
Depend on model
60.00Hz
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
60.00Hz
2
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
300
