Fault Information - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Response (From VFD to master)
Response 00
Example for PZD:
Transmission of PZD area is achieved through VFD function code; please refer to related INVT VFD
user manual to know related function code.
Example 1: Read process data of VFD
VFD parameter selects "8: Running rotation speed" as PZD3 to transmit which can be achieved by
setting P15.14 as 8. This operation is mandatory until the parameter is instead of others.
Request (From master to VFD):
PKW1
Response xx xx xx xx xx xx
Example 2: Write process data into VFD
VFD parameter selects "2": PID Reference" from PZD3 which can be achieved by setting P15.03 as 2.
In each request frame, parameters will use PZD3 to update until re-select a parameter.
Request (From master to converter):
PKW1
Response xx xx xx xx xx xx
In each request frame contents of PZD3 are given by traction until re-select a parameter.
A.2.9 Fault information
EC-TX-103 communication card is equipped with 2 fault display LEDs as shown is figure below. The
roles of these LEDs are as follows:
PKW1 PKW2 PKW3
01 00 10 00
0001: Response (parameter values refreshed)
PKW2 PKW3
PKW2 PKW3
PKW4 CW CW
00 50 00 xx xx
PKW4 CW
xx xx xx xx
PKW4 CW
xx xx xx xx
-225-
PZD2 PZD3 ...
xx xx xx xx ...
PZD2 PZD3
xx xx 00 0A
PZD2 PZD3
xx xx 00 00
Expansion card
PZD12
xx xx
...
PZD12
...
xx xx
...
PZD12
...
xx xx
