GD310-UL series VFD
Function
code
P10.24
P10.25 The running time of step 11 0.0–6553.5s (min)
P10.26
P10.27 The running time of step 12 0.0–6553.5s (min)
P10.28
P10.29 The running time of step 13 0.0–6553.5s (min)
P10.30
P10.31 The running time of step 14 0.0–6553.5s (min)
P10.32
P10.33 The running time of step 15 0.0–6553.5s (min)
P10.36
Simple PLC 0–7 step
P10.34
Simple PLC 8–15 step
P10.35
P05.01–P05.
09
P06.01–P06. Digital output function
04
P17.00
Simple PLC and the current
P17.27
stage of the multi-step speed

7.14 Multi-step speed running

Set the parameters when the VFD carries out multi-step speed running. Goodrive310-UL series VFDs
can set 16 stage speed which can be selected by the combination code of multi-step speed terminals
1–4. They correspond to multi-step speed 0 to 15.
Name
Multi-step speed 11
Multi-step speed 12
Multi-step speed 13
Multi-step speed 14
Multi-step speed 15
PLC restart
ACC/DEC time
ACC/DEC time
Digital input function
selection
selection
Setting frequency
Description
-100.0–100.0%
-100.0–100.0%
-100.0–100.0%
-100.0–100.0%
-100.0–100.0%
0: Restart from the first stage
1: Continue to run from the stop frequency
0x0000–0XFFFF
0x0000–0XFFFF
23: Simple PLC stop reset
24: Simple PLC pause
15: Underload pre-alarm
16: Completion of simple PLC stage
0.00Hz–P00.03 (max output frequency)
0–15
-158-
Basic operation instruction
Default
value
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0
0000
0000
0.00Hz
