INVT Goodrive 310-UL Series Operation Manual page 125

GD310-UL series VFD
Function
code
Rated power of
P02.01
asynchronous motor 1
Rated frequency of
P02.02
asynchronous motor 1
Rated speed of
P02.03
asynchronous motor 1
Rated voltage of
P02.04
asynchronous motor 1
Rated current of
P02.05
asynchronous motor 1
Rated power of
P02.15
synchronous motor 1
Rated frequency of
P02.16
synchronous motor 1
Number of poles pairs
P02.17
for synchronous motor 1
Rated voltage of
P02.18
synchronous motor 1
Rated current of
P02.19
synchronous motor 1
Multi-function digital
P05.01–P0 input terminals
5.09 (S1–S8, HDI) function
P07.01 Parameter copy
Name
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–36000rpm
0–1200V
0.8–6000.0A
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–50
0–1200V
0.8–6000.0A
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
selection
The function code determines the manner of
parameters copy.
0: No operation
1: Upload the local function parameter to the
keypad
2: Download the keypad function parameter to
local address (including the motor parameters)
3: Download the keypad function parameter to
local address (excluding the motor parameter
of P02 and P12 group)
4: Download the keypad function parameters to
local address (only for the motor parameter of
P02 and P12 group)
Description
-117-
Basic operation instruction
Default
value
Depend on
model
60.00Hz
Depend on
model
Depend on
model
Depend on
model
Depend on
model
60.00Hz
2
Depend on
model
Depend on
model
0
