INVT Goodrive 310-UL Series Operation Manual page 149

GD310-UL series VFD
Function
code
Integral ratio of the
P08.43
keypad potentiometer
UP/DOWN terminals
P08.44
UP terminals frequency
P08.45
DOWN terminals
P08.46 frequency changing
P17.00 Setting frequency
Ramp reference
P17.02
P17.14 Digital adjustment
Name
control
changing ratio
ratio
frequency
Description
0: Setting is valid
1: Valid during running, cleared after stopping
2: Valid during running, cleared after
receiving the stop command
LED thousands: ∧/∨ keys and digital
potentiometer Integral function
0: The Integral function is valid
1: The Integral function is invalid
0.01–10.00s
0x00–0x221
LED ones: frequency control selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step are priority, it is invalid
to the multi-step
LED hundreds: action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving
the stop commands
0.01–50.00Hz/s
0.01–50.00 Hz/s
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
Display current ramp given frequency of the
VFD
Range: 0.00Hz–P00.03
Display the adjustment through the keypad of
the VFD.
Range : 0.00Hz–P00.03
-141-
Basic operation instruction
Default
value
0.10s
0x000
0.50 Hz/s
0.50 Hz/s
0.00Hz
0.00Hz
0.00V
