INVT Goodrive 310-UL Series Operation Manual page 80

GD310-UL series VFD
Function
Name
code
Y1 switch-on
P06.06
delay time
Y1 switch-off
P06.07
delay time
HDO
P06.08 switch-on
delay time
HDO
P06.09 switch-off
delay time
RO1 switch-on
P06.10
delay time
RO1 switch-off
P06.11
delay time
RO2 switch-on
P06.12
delay time
RO2 switch-off
P06.13
delay time
P06.14 AO1 output
P06.15 AO2 output
HDO
P06.16 high-speed
pulse output
The function code defines the corresponding delay
time of the electrical level change during the
programmable terminal switching on and off.
Y electric level
Invalid
Y valid
Switch on
delay
The setting range: 0.000–50.000s
Note: P06.08 and P06.08 are valid only when
P06.00=1.
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running rotation speed (relative to twice the motor
synchronous speed)
4: Output current (relative to twice the rated current
of the VFD)
5: Output current (relative to twice the rated current
of the motor)
6: Output voltage (relative to 1.5 times the rated
voltage of the VFD)
7: Output power (relative to twice the rated power of
the motor)
8: Set torque value (relative to twice the rated torque
of the motor)
9: Output torque (relative to twice the rated torque of
the motor)
10: AI1 input value
11: AI2 input value
Description
Valid
Switch off
delay
-72-
Function parameter
Default
value
0.000s
0.000s
0.000s
0.000s
invalid
0.000s
0.000s
0.000s
0.000s
0
0
0
Modify
○
○
○
○
○
○
○
○
○
○
○
