INVT Goodrive 310-UL Series Operation Manual page 245

GD310-UL series VFD
Floor installation of 460V G-type 350–500kW, P-type 400–500kW VFDs
Floor installation dimension of 460V G-type 220–500kW VFDs (unit: mm)
Model
GD310-(220G-315G)-4-UL
GD310-(350G-500G)-4-UL
Floor installation dimension of 460V P-type 250–500kW VFDs (unit: mm)
Model
GD310-(220P-315P)-4-UL
GD310-(350P-500P)-4-UL
W1 W2 W3 W4
750 230 714 680
620 230 573
W1 W2 W3 W4
750 230 714 680
620 230 573
-237-
H1 H2
1410 1390
/ 1700 1678
H1 H2
1410 1390
/ 1700 1678
Dimension drawings
Installation
D1 D2
hole
380 150 Ø13/12
560 240 Ø22/12
Installation
D1 D2
hole
380 150 Ø13/12
560 240 Ø22/12
