INVT Goodrive 310-UL Series Operation Manual page 160

GD310-UL series VFD
Function
code
Polarity selection of input
P05.10
P05.11 ON-OFF filter time
P05.12 Virtual terminals setting
Terminals control running
P05.13
P05.14 Switch-on delay of S1 terminal 0.000–50.000s
P05.15 Switch-off delay of S1 terminal 0.000–50.000s
P05.16 Switch-on delay of S2 terminal 0.000–50.000s
P05.17 Switch-off delay of S2 terminal 0.000–50.000s
P05.18 Switch-on delay of S3 terminal 0.000–50.000s
P05.19 Switch-off delay of S3 terminal 0.000–50.000s
P05.20 Switch-on delay of S4 terminal 0.000–50.000s
P05.21 Switch-off delay of S4 terminal 0.000–50.000s
P05.22 Switch-on delay of S5 terminal 0.000–50.000s
P05.23 Switch-off delay of S5 terminal 0.000–50.000s
P05.24 Switch-on delay of S6 terminal 0.000–50.000s
Name
terminal
mode
Description
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Consumption power clear
41: Consumption power holding
42–63: Reserved
61: PID pole switching
62–63: Reserved
0x000–0x1FF
0.000–1.000s
0x000–0x1FF (0: Disabled, 1: Enabled )
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
0: 2-wire control 1
1: 2-wire control 2
2: 3-wire control 1
3: 3-wire control 2
-152-
Basic operation instruction
Default
value
0x000
0.010s
0x000
0
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
