GD310-UL series VFD
Function
code
Multi-function digital input
P05.01–
terminals (S1–S8, HDI)
P05.09
function selection
P08.31
P12.00
P12.01 Rated power of AM 2
P12.02 Rated frequency of AM 2
P12.03 Rated speed of AM 2
P12.04 Rated voltage of AM 2
P12.05 Rated current of AM 2
P12.06 Stator resistor of AM 2
P12.07 Rotor resistor of AM 2
P12.08 Leakage inductance of AM 2 0.1–6553.5mH
P12.09 Mutual inductance of AM 2
P12.10 Non-load current of AM 2
P12.15 Rated power of SM 2
P12.16 Rated frequency of SM 2
Number of poles pairs for SM
P12.17
P12.18 Rated voltage of SM 2
P12.19 Rated current of SM 2
P12.20 Stator resistor of SM 2
Direct axis inductance of SM
P12.21
Name
Motor shifting
Motor type 2
2
2
Description
35: Shift from motor 1 to motor 2
LED ones: shifting channel
0: terminal shifting
1: MODBUS communication shifting
2: PROFIBUS/CANopen
communication shifting
3: Ethernet communication shifting
4: Reserved
LED tens: shifting enabling in
operation
0: Disabled
1: Enabled
0x00–0x14
0: Asynchronous motor
1: Synchronous motor
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–36000rpm
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5A
0.1–3000.0kW
0.01Hz–P00.03 (the max frequency)
1–50
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.01–655.35mH
-133-
Basic operation instruction
Default value
00
0
Depend on model
60.00Hz
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
Depend on model
60.00Hz
2
Depend on model
Depend on model
Depend on model
Depend on model
