INVT Goodrive 310-UL Series Operation Manual page 229

GD310-UL series VFD
State word (SW):
The first word of PZD response message is state word (SW) of VFD, the definition of state word is as
follows:
State Word (SW) of Goodrive310-UL
Bit
0–7 Run state byte
8 Dc voltage establish
9–10 Motor group feedback
11 Motor type feedback
12 Overload alarm
13
Run/stop mode
14
15 Heartbeat feedback
Actual value (ACT):
nd
From 2 word to 12
offered by main setting signal source.
Actual value of Goodrive310-UL
Bit
PZD2 sending
PZD3 sending
PZD4 sending
PZD5 sending
Name Value
th
of PZD task message is main set value ACT, main frequency set value is
0: Invalid
1: Running frequency (*100, Hz)
2: Set frequency (*100, Hz)
3: Bus voltage (*10, V)
1 Forward running
2 Reverse running
3 The VFD stops
4 The VFD is in fault
5 The VFD is in POFF state
6 Pre-exciting state
1 Running ready
0 The running preparation is not ready
0 Motor 1 feedback
1 Motor 2 feedback
2 Motor 3 feedback
3 Motor 4 no feedback
1 Synchronous motor
0 Asynchronous motor
1 Overload pre-alarm
0 Non-overload pre-alarm
0 Keypad control
1 Terminal control
2 Communication control
3 Reserved
1 Heartbeat feedback
0 No heartbeat feedback
Name
-221-
State/Description
Function selection
Expansion card
0
0
0
0
