INVT Goodrive 310-UL Series Operation Manual page 83

GD310-UL series VFD
Function
Name
code
QUICK/JOG
P07.02 function
selection
Shifting
P07.03 sequence
selection of
1: Upload the local function parameter to the keypad
2: Download the keypad function parameter to local
address (including the motor parameters)
3: Download the keypad function parameter to local
address (excluding the motor parameter of P02 and
P12 group)
4: Download the keypad function parameters to local
address (only for the motor parameter of P02 and
P12 group)
Note: After completing the 1–4 operations, the
parameter will come back to 0 automatically; the
function of upload and download excludes the factory
parameters of P29.
0: No function
1: Jogging. Press QUICK/JOG to begin the jogging
running.
2: Shift the display state by the shifting key. Press
QUICK/JOG to shift the displayed function code from
right to left.
3: Shift between forward rotations and reverse
rotations. Press QUICK/JOG to shift the direction of
the frequency commands. This function is only valid
in the keypad commands channels.
4: Clear UP/DOWN settings. Press QUICK/JOG to
clear the set value of UP/DOWN.
5: Coast to stop. Press QUICK/JOG to coast to stop.
6: Shift the given manner of running commands.
Press QUICK/JOG to shift the given manner of
running commands.
7: Quick commissioning mode (committee according
to the non-factory parameter)
Note: Press QUICK/JOG to shift between forward
rotation and reverse rotation, the VFD does not
remember the state after shifting during powering off.
The VFD will run in the running direction set
according to P00.13 during next powering on.
When P07.02=6, set the shifting sequence of running
command channels.
0: Keypad control→terminals control
Description
-75-
Function parameter
Default
Modify
value
◎
1
○
0
