P11 Group Protective Parameters - INVT Goodrive 310-UL Series Operation Manual

GD310-UL series VFD
Function
Name
code
PLC restart
P10.36
Multi-step time
P10.37
unit

P11 Group Protective parameters

Function
Name
code
Phase loss
P11.00
protection
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.35
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
After users select the corresponding ACC/DEC time,
the combining 16 binary bit can be changed into
hexadecimal bit, and then set the corresponding
function codes.
ACC/DEC time 1 is set by P00.11 and P00.12;
ACC/DEC time 2 is set by P08.00 and P08.01;
ACC/DEC time 3 is set by P08.02 and P08.03;
ACC/DEC time 4 is set by P08.04 and P08.05.
Setting range: -0x0000–0xFFFF
0: Restart from the first step; stop during running
(caused by the stop command, fault or power loss),
run from the first stage after restart.
1: Continue to run from the stop frequency; stop
during running (caused by stop command and fault),
the VFD will record the running time automatically,
enter into the stage after restart and keep the
remaining running at the setting frequency.
0: Seconds; the running time of all steps is counted
by second
1: Minutes; the running time of all steps is counted by
minute
0x00–0x11
Ones:
0: Disable input phase loss protection
1: Enable input phase loss protection enable
Tens:
Description
8 00 01
9 00 01
10 00 01
11 00 01
12 00 01
13 00 01
14 00 01
15 00 01
Description
-95-
Function parameter
Default
value
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
0
0
Default
value
11
Modify
◎
◎
Modify
○
