INVT Goodrive 310-UL Series Operation Manual page 158

GD310-UL series VFD
Set
Function
value
Frequency
33 increasing/decreasing
setting temporal clear
34 DC braking
Switch between motor1 and
35
motor2
Switch commands to
36
keypad
Switch commands to
37
terminals
Switch commands to
38
communication
39 Pre-excitation commands
40 Power consumption clear
Power consumption
41
retention
42–60 Reserved
61 PID pole switching
62–63 Reserved
Related parameters list:
Function
code
P05.00 HDI input selection
P05.01 S1 terminals function selection 0: No function
P05.02 S2 terminals function selection
P05.03 S3 terminals function selection
When the terminal closes, the frequency set by UP/DOWN
can be cleared. All set frequency will be restored into the
given frequency by the frequency command channel and the
frequency will come back to the value after the frequency
increasing or decreasing.
The VFD will begin DC braking after the valid command.
Motor-shifting can be controlled after the terminal is valid.
After the function terminal become valid, the running
command channel will be shifted into keypad running
command channel and the running command channel will
come back to the original state if function terminal is invalid.
After the function terminal become valid, the running
command channel will be shifted into terminal running
command channel and the running command channel will
come back to the original state if function terminal is invalid.
After the function terminal become valid, the running
command channel will be shifted into communication running
command channel and the running command channel will
come back to the original state if function terminal is invalid.
Perform pre-exciting if the terminal is valid until the terminal is
invalid.
The power consumption will be cleared after the command is
valid.
If the command is valid, the current running of the VFD will
not affect its power consumption.
Switch the output pole of PID and be used with P09.03
Name
0: High pulse input
1: Digital input
1: Forward rotation operation
2: Reverse rotation operation
Instructions
Description
-150-
Basic operation instruction
Default
value
0
1
4
7
