GD310-UL series VFD
C.5 Dimensions for VFDs of AC 3PH 520V(-10%)
C.5.1 Wall installation
Wall installation dimension of 575V 18.5–110kW VFDs (unit: mm)
Model
GD310-(018G-037G)-6-UL
GD310-(045G-110G)-6-UL
C.5.2 Flange installation
Flange installation dimension of 575V 18.5–110kW VFDs (unit: mm)
Model
GD310-(018G-037G)-6-UL 270 130 261 65.5 555 540 516
GD310-(045G-110G)-6-U 325 200 317 58.5 680 661 626
Wall installation of 575V 18.5–110kW VFDs
W1 W2
270 130
325 200
Flange installation of 575V 18.5–110kW VFDs
W1 W2 W3 W4
–
600V(+10%)
H1 H2
555 540
680 661
H1 H2 H3
-238-
Dimension drawings
D1 Installation hole
325 Ø7
365 Ø9.5
Installation
H4 D1 D2
hole
17 325 167
23 363 182 Ø9.5
Ø7
