GD310-UL series VFD
Set
Function
value
POROFIBUS
communication
24
virtual terminal
output
Voltage
26 establishment
finished
27–30 Reserved
Related parameters list:
Function
code
P06.00 HDO output
P06.01
P06.02 HDO output
P06.03 Relay RO1 output
P06.04 Relay RO2 output
Output corresponding signal according to the setting value of
PROFIBUS/CANOPEN. Output ON signal if the setting value is 1 and
output OFF signal if the setting value is 0.
The output is valid when the bus voltage reaches the undervoltage
point.
Name
0: Open collector pole high speed pulse output
1: Open collector pole output
Y output 0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Length arrival
22: Running time arrival
Instructions
Description
-155-
Basic operation instruction
Default
value
0
0
0
1
5
