GD310-UL series VFD
Function
Name
code
Communicatio
P00.02 n running
commands
Max. output
P00.03
frequency
Upper limit of
P00.04 the running
frequency
Lower limit of
P00.05 the running
frequency
A frequency
P00.06
command
1: Terminal running command channel
("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward jogging
and reverse jogging of the multi-function terminals
2: Communication running command channel
("LOCAL/REMOT" on);
The running command is controlled by the upper
monitor via communication
Select the controlling communication command
channel of the VFD.
0: MODBUS communication channel
1: PROFIBUS/CANopen communication channel
2: Ethernet communication channel
3: Reserved
Note: 1, 2 and 3 are extended functions which need
corresponding expansion cards.
This parameter is used to set the maximum output
frequency of the VFD. Users should pay attention to
this parameter because it is the foundation of the
frequency setting and the speed of acceleration and
deceleration.
Setting range: P00.04–400.00Hz
The upper limit of the running frequency is the upper
limit of the output frequency of the VFD which is
lower than or equal to the maximum frequency.
Setting range: P00.05–P00.03 (Max. output
frequency)
The lower limit of the running frequency is that of the
output frequency of the VFD.
The VFD runs at the lower limit frequency if the set
frequency is lower than the lower limit one.
Note: Max. output frequency ≥ Upper limit frequency
≥ Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper limit of the
running frequency)
0: Keypad
Modify the value P00.10 (set the frequency by
Description
-40-
Function parameter
Default
Modify
value
○
0
◎
60.00Hz
◎
60.00Hz
◎
0.00Hz
○
0
