INVT Goodrive 310-UL Series Operation Manual page 216

GD310-UL series VFD
Function
instruction definition
The address of
communication
setting
Set P00.01 to 2 and P00.06 to 8.
The command sent to the VFD:
Continuous
VFD
writing
address
command
If the response message is as below:
Example 2: set the ACC time of 01H VFD as 10s and the DEC time as 20s
Function
Name
code
P00.11 ACC time 1
P00.12 DEC time 1
The corresponding address of P00.11 is 000B, the ACC time of 10s corresponds to 0064H, and the
DEC time of 20s corresponds to 00C8H.
The command sent to the VFD:
Address
0004H: reverse jogging
0005H: stop
0006H: coast to stop
0007H: fault reset
0008H: jogging stop
2001H Communication setting frequency (0–Fmax (unit: 0.01Hz))
2002H PID given, range (0–1000, 1000 corresponds to100.0%)
Parameters
address
Continuous
VFD
writing
address
command
ACC time means the time needed if the VFD
speeds up from 0Hz to the max One (P00.03).
DEC time means the time needed if the VFD
speeds down from the max Output frequency to
0Hz (P00.03).
Goodrive310-UL series VFDs define four groups of
ACC/DEC time which can be selected by P05. The
factory default ACC/DEC time of the VFD is the first
group.
Setting range: 0.0–3600.0s
Data meaning instruction
Data Byte
number number
Parameters
Data
address
number
Description
-208-
Communication protocol
Forward
10Hz
running
CRC check
Default
value
Depend on
model
Depend on
model
R/W
attribute
R/W
CRC check
Modify
○
○
