GD310-UL series VFD
Function
code
B frequency command
P00.08
Combination of the
P00.09
Multi-function digital
P05.01–P05.
09 (S1–S8, HDI) function
P08.42 Keypad data control
Name
reference
setting source
input terminals
selection
Description
7: PID control setting
8: MODBUS communication setting
9: PROFIBUS/CANopen communication
setting
10: Ethernet communication setting (reserved)
11: Reserved
0: Maximum output frequency
1: A frequency command
0: A
1: B
2: (A+B) combination
3: (A-B) combination
4: Max (A, B) combination
5: Min (A, B) combination
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
0x000–0x1223
LED ones: frequency enable selection
0: Both ∧/∨ keys and digital potentiometer
adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only digital potentiometer adjustments is
valid
3: Neither ∧/∨ keys nor digital potentiometer
adjustments are valid
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when
multi-step speed has the priority
LED hundreds: action selection during
stopping
-140-
Basic operation instruction
Default
value
0
0
0x0000
