INVT Goodrive 310-UL Series Operation Manual page 209

GD310-UL series VFD
Function
instruction
SW 1 of the VFD
SW 2 of the VFD
Fault code of the
VFD
Identifying code of
the VFD
Address
definition
Special control command word
Bit0–1:=00: motor 1
=10: motor 3
Bit2:=1 torque control prohibit
=0: torque control prohibit invalid
2009H Bit3:=1 power consumption clear
=0:no power consumption clear
Bit4:=1 pre-exciting enabling
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
200AH Virtual input terminal command , range: 0x000–0x1FF
200BH Virtual output terminal command , range: 0x00–0x0F
Voltage setting value (special for V/F separation)
200CH
(0–1000, 1000 corresponds to the 100.0%)
AO output setting 1
200DH
(-1000–1000, 1000 corresponds to 100.0%)
AO output setting 2
200EH
(-1000–1000, 1000 corresponds to 100.0%)
0001H: forward running
0002H: forward running
0003H: stop
2100H
0004H: fault
0005H: POFF state
0006H: pre-exciting state
Bit0: =0:ready for operation =1:not ready for operation
Bi1–2:=00:motor 1
=10:motor 3
Bit3: =0:asynchronous motor =1:synchronous motor
2101H Bit4: =0:pre-alarm without overload =1:overload
pre-alarm
Bit5– Bit6: =00: keypad control
=01: terminal control
=10: communication control
2102H See the fault type instruction
2103H GD310-----0x010a
Data meaning instruction
=01: motor 2
=11: motor 4
=01:motor 2
=11:motor 4
-201-
Communication protocol
R/W
attribute
R/W
R/W
R/W
R/W
R/W
R/W
R
R
R
R
