INVT Goodrive 310-UL Series Operation Manual page 108

GD310-UL series VFD
Function
Name
code
Rated
frequency of
P12.02
asynchronous
motor 2
Rated speed
of
P12.03
asynchronous
motor 2
Rated voltage
of
P12.04
asynchronous
motor 2
Rated current
of
P12.05
asynchronous
motor 2
Stator resistor
of
P12.06
asynchronous
motor 2
Rotor resistor
of
P12.07
asynchronous
motor 2
Leakage
inductance of
P12.08
asynchronous
motor 2
Mutual
inductance of
P12.09
asynchronous
motor 2
0.01Hz–P00.03
(the max frequency)
1–36000rpm
0–1200V
0.8–6000.0A
0.001–65.535Ω
0.001–65.535Ω
0.1–655.35mH
0.1–655.35mH
Description
controlling performance, set
the P12.01–P12.05
according to the name plate
of the asynchronous motor.
Goodrive310-UL series
VFDs provide the function of
parameter autotuning.
Correct parameter
autotuning comes from the
correct setting of the motor
name plate.
In order to ensure the
controlling performance,
please configure the motor
according to the standard
principles, if the gap
between the motor and the
standard one is huge, the
features of the VFD will
decrease.
Note: reset the rated power
of the motor (P12.01),
initialize the motor
parameter of
P12.02–P12.05
After finish the motor
parameter autotuning, the
set value of P12.06–P12.10
will renew automatically.
These parameters are basic
parameters controlled by
vectors which directly
impact the features.
Note: Users cannot modify
the parameters freely.
-100-
Function parameter
Default
Modify
value
◎
60.00Hz
Depend
◎
on model
Depend
◎
on model
Depend
◎
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
