GD310-UL series VFD
Function
Name
code
Fault time of
CANopen
P15.26
communica
-tion overtime
CANopen
P15.27
baud rate

P16 Group Ethernet function

Function
Name
code
Speed setting
P16.00 of Ethernet
communication
P16.01 IP address 1 0–255
P16.02 IP address 2
P16.03 IP address 3
P16.04 IP address 4
P16.05 Subnet mask 1 0–255
P16.06 Subnet mask 2
P16.07 Subnet mask 3
P16.08 Subnet mask 4
0.0 (invalid), 0.1–60.0s
When this function code is set as 0.0, this function is
invalid.
When the function code is set as nonzero value, if
the internal time
communication exceeds
overtime, the system
communication fault" (E-CAN)
0: 1000k
1: 800k
2: 500k
3: 250k
4: 125k
5: 100k
6: 50k
7: 20k
0: Self-adapting
1: 100M full duplex
2: 100M semiduplex
3: 10M full duplex
4: 10M semiduplex
The function code is used to set the Ethernet
communication speed.
Set the IP address of Ethernet communication
The format of IP address:
P16.09.P16.10.P16.11.P16.12
For example: IP address is 192.168.0.1.
Set the subnet mask of Ethernet communication.
The format of IP subnet mask:
P16.13.P16.14.P16.15.P16.16.
For example: The mask is 255.255.255.0.
Description
between two
the communication
will report
Description
-110-
Function parameter
Default
value
0.0s
adjacent
"CANopen
0
Default
value
0
192
168
0
1
255
255
255
0
Modify
●
Modify
◎
◎
◎
◎
◎
◎
◎
◎
◎
